0.8 mm Pitch SMT Board to Board Connector, Plug, 13.05mm Stack Height
Introduction:
Optimize your high-density electronic designs with this premium 0.8 mm Pitch SMT Board to Board Connector. Featuring a dual-row plug (male) configuration, this high-performance vertical component provides a precise 13.05mm stack height, making it the ideal solution for compact space-saving applications. Engineered for seamless surface mount (SMT) integration, it ensures robust and reliable parallel PCB connections across a flexible range of 20 to 160 positions.
Crafted from superior copper alloy with excellent gold flash contact plating, this connector guarantees optimal signal integrity and maximum corrosion resistance. The housing is molded from high-temperature thermoplastic, built to withstand harsh processing environments and demanding operating conditions. Perfect for industrial, automotive, and consumer electronics, this vertical board-to-board interconnect delivers unparalleled mechanical stability and electrical efficiency.
Key Features
- 0.8mm Micro Pitch: High-density dual-row vertical SMT design for compact PCBs.
- 13.05mm Stack Height: Elevates board-to-board spacing with parallel precision.
- 20-160 Positions: Scalable configuration options to meet diverse circuitry needs.
- Gold Flash Plating: Premium copper alloy contacts ensure superior conductivity.
- UL 94 V-0 Rated: Flame-retardant, high-temperature thermoplastic insulation for safety.
- Rugged Durability: Engineered to perform reliably from -40°C up to +85°C.
Main Specifications:
General Information:
| Product No.: | YC-BB8-PA-XXX-G-13.05-PP-TR | |
| Category: | Board to Board Connectors | |
| Centerline (Pitch) | 0.8mm (0.0315″) Pitch | |
| Gender: | Male | |
| Number of Rows: | Dual Row | |
| Number of Positions: | 20-160 Positions | |
| Mounting Orientation: | Vertical | |
| Termination Style: | Press Fit | |
| Mounting Type: | Surface Mount | |
| Height Above Board: | 13.05mm | |
| Other Feature: | None |
Electrical:
| Current rating: | 0.5A | |
| Dielectric withstanding voltage: | 500 VAC | |
| Mating Cycles | 100 Cycles |
Materials and Plating:
| Contact Material: | Copper Alloy | |
| Contact plating: | Gold flash over Nickel underplate overall | |
| Insulator: | Hi-temp thermoplastic |
Environmental:
| Operating Temperature: | -40℃ to +85℃ | |
| Flammability Rating: | UL 94 V-0 |
Applications of this 0.8 mm Pitch SMT Board to Board Connector:
Board-to-board connectors are fundamental components in modular electronics, facilitating robust signal and power transmission between stacked or adjacent printed circuit boards (PCBs).
- Consumer Electronics
- Industrial Equipment
- Medical Devices
- Communication Equipment
- Automotive Electronics
- Embedded Computing Systems
- IoT Infrastructure
- Test and Measurement Instruments
- Aerospace and Defense Electronics
- Robotics and AI Systems
