Waterproof Motorcycle Power & Signal Hybrid Electrical Connector, 2+1+7 Pin
Introduction
The waterproof motorcycle power & signal hybrid electrical connector delivers an all-in-one connectivity solution engineered for high-performance electric motorcycles, e-scooters, and light EV platforms. Designed to eliminate cable clutter, it integrates heavy-duty power delivery and low-noise data transmission into a single, compact interface.
Built for rugged riding conditions, this hybrid connector features an IPX7 waterproof rating and a wide operating temperature range of -40°C to 105°C. With a flame-retardant UL94V-0 housing and high dielectric withstand voltage, it ensures maximum electrical safety, battery protection, and long-term durability against extreme weather, vibration, and thermal shock.
Key Features:
- Hybrid 2+1+7 Pin Design: Combines power and signal integration in one compact body.
- Heavy-Duty Current: Supports 100A + 25A power lines and 5A signal lines.
- Dual Voltage Support: Rated for 630V DC (Power) and 100V DC (Signal).
- High Dielectric Safety: Withstand voltage up to 2,500V AC (Power) and 2,000V AC (Signal).
- IPX7 Waterproof Protection: Fully sealed against water immersion and road spray.
- All-Weather & Flame Retardant: Flame-rated UL94V-0 with operating temperatures from -40°C to 105°C.
Main Specifications:
General Information:
| Part No.: | YC-E1001-003 | |
| Product Series: | Electric Motorcycle Connectors | |
| Brand: | Metabee | |
| Number of Positions: | 2+1+7 Pin | |
| Wire Gauge: | Power 25mm, Signal 20AWG/Max |
|
| Other Feature: | None |
Electrical Performance:
| Rated Voltage: | 630V DC (Power), 100v Dc (Signal) | |
| Rated Current: | 100A+25A+5A | |
| Insulation Resistance: | 100MΩ at DC 500V | |
| Withstanding Voltage: | 2,500V AC (Power), 2000V AC (Signal) |
|
| Durability (Mating): | ≥3000 Cycles |
Environmental Performance:
| IP Rating: | IPX7 | |
| Salt Spray: | 5% NaCl, 48h | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -40°C to +105°C |
Applications:
Electric motorcycle connectors provide reliable power and signal transmission for electric two-wheelers and related mobility systems.
Here are some main applications:
- Electric Motorcycles
- Electric Scooters
- Electric Moped Systems
- Battery Pack Connections
- Battery Charging System
- Motor Controllers
- Battery Management Systems (BMS)
- Electric Motorcycle Wiring Harnesses
- Electric Delivery Motorcycles
- Electric Off-Road Motorcycles
