E-Motorcycle E-Bike Battery Power & Signal Hybrid Charger, 2+3 Pin, IP67
Introduction
This hybrid charger integrates battery power and signal transmission in a compact 2+3 pin layout, reducing cable count on e-motorcycles and e-bikes. The design supports stable charging and reliable data communication in one connection.
Engineered for tough environments, the connector meets UL94V-0 flame-retardant standards and carries an IP67 waterproof rating. It performs consistently from -40°C to 105°C, ensuring dependable operation in rain, dust, and temperature extremes.
Key Features:
- 2+3 pin hybrid power and signal design
- IP67 waterproof and dustproof protection
- UL94V-0 flame-retardant housing
- Wide -40°C to 105°C operating range
- Stable charging and signal transmission
- Compact layout for simplified wiring
Main Specifications:
General Information:
| Part No.: | YC-E1001-0020 | |
| Product Series: | Electric Motorcycle Connectors | |
| Brand: | Metabee | |
| Number of Positions: | 2+3 Pin | |
| Wire Gauge: | Power 14AWG/ 2.0mm² Signal 22AWG/ 0.32mm² |
|
| Other Feature: | None |
Electrical Performance:
| Rated Voltage: | 48V AC / 60V DC | |
| Rated Current: | 20A+2A | |
| Insulation Resistance: | 20MΩ at 500V DC | |
| Withstanding Voltage: | 1,000V AC | |
| Durability (Mating): | ≥3000 Cycles |
Environmental Performance:
| IP Rating: | IP67 | |
| Salt Spray: | 5% NaCl, 48h | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -40°C to +105°C |
Applications:
Electric motorcycle connectors provide reliable power and signal transmission for electric two-wheelers and related mobility systems.
Here are some main applications:
- Electric Motorcycles
- Electric Scooters
- Electric Moped Systems
- Battery Pack Connections
- Battery Charging System
- Motor Controllers
- Battery Management Systems (BMS)
- Electric Motorcycle Wiring Harnesses
- Electric Delivery Motorcycles
- Electric Off-Road Motorcycles
