2 Pin Electric Motorcycle BMS Signal Connector, IP66
Introduction
Ensure precise battery management monitoring with this compact 2-pin signal connector. Designed specifically for electric motorcycles, e-scooters, and light electric vehicles, it provides low-resistance, uninterrupted communication between the battery pack, controller, and onboard diagnostic modules.
Built to withstand severe road environments, the connector features a robust UL94V-0 flame-retardant housing paired with an IP66 sealing standard. It prevents dust ingress, blocks high-pressure water spray, and delivers vibration-proof stability across demanding operational conditions.
Key Features:
- Dedicated 2-Pin Layout: Delivers secure, low-loss signal transmission tailored for BMS diagnostics and sensor monitoring.
- IP66 Ingress Protection: Completely dust-tight and resistant to strong water jets, road wash, and heavy rain.
- UL94V-0 Flame Retardance: High-temperature self-extinguishing casing provides superior fire resistance and battery safety.
- Extreme Temperature Tolerance: Maintains reliable electrical integrity across -40°C to 105°C thermal extremes.
- Anti-Vibration Reliability: Tight-locking mechanism prevents signal disruption or accidental decoupling on rough terrains.
- Compact Footprint: Space-efficient design easily integrates into constrained electric two-wheeler battery compartments.
Main Specifications:
General Information:
| Part No.: | YC-E1001-0048 | |
| Product Series: | Electric Motorcycle Connectors | |
| Brand: | Metabee | |
| Number of Positions: | 2 Pin | |
| Wire Gauge: | 28AWG/0.08mm² | |
| Other Feature: | None |
Electrical Performance:
| Rated Voltage: | 48V AC/60V DC | |
| Rated Current: | 2A | |
| Insulation Resistance: | 20MΩ at 500V DC | |
| Withstanding Voltage: | 500V AC | |
| Durability (Mating): | 200 Cycles |
Environmental Performance:
| IP Rating: | IP66 | |
| Salt Spray: | 5% NaCl, 48h | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -40°C to +105°C |
Applications:
Electric motorcycle connectors provide reliable power and signal transmission for electric two-wheelers and related mobility systems.
Here are some main applications:
- Electric Motorcycles
- Electric Scooters
- Electric Moped Systems
- Battery Pack Connections
- Battery Charging System
- Motor Controllers
- Battery Management Systems (BMS)
- Electric Motorcycle Wiring Harnesses
- Electric Delivery Motorcycles
- Electric Off-Road Motorcycles
