Electric Bicycle/Scooter/Motorcycle Lithium Battery Charger, 3+8 Pin, IP66
Introduction
Engineered for reliable e-mobility charging, this high-performance connector is designed specifically for electric bicycles, scooters, and motorcycles. Featuring an advanced 3+8 pin configuration, it separates heavy power delivery from precision signal feedback, ensuring stable current transfer and smart battery management.
Built to withstand demanding outdoor and road conditions, the connector features an IP66 waterproof rating and an ultra-wide operating range from -40°C to 105°C. Constructed from certified UL94 V-0 flame-retardant material, it provides maximum thermal protection and long-term durability for lithium-ion battery systems.
Key Features:
- Pin Configuration: Hybrid 3+8 pin layout isolating high power from smart data communication.
- Fire Safety: UL94 V-0 flame-retardant housing minimizes fire risks under heavy electrical loads.
- Ingress Protection: IP66 rating seals against heavy rain, dust, and washdowns.
- Extreme Temperatures: Stable performance across harsh environments from -40°C to 105°C.
- Broad Compatibility: Tailored for electric bikes, scooters, and light electric motorcycles.
- Safe Charging: Built for high-efficiency lithium battery systems with enhanced terminal reliability.
Main Specifications:
General Information:
| Part No.: | YC-E1001-0024 | |
| Product Series: | Electric Motorcycle Connectors | |
| Brand: | Metabee | |
| Number of Positions: | 3+8 Pin | |
| Wire Gauge: | 18AWG/0.82mm² + 26AWG/0.12mm² | |
| Other Feature: | None |
Electrical Performance:
| Rated Voltage: | 48V AC/60V DC | |
| Rated Current: | 16A+2A | |
| Insulation Resistance: | 20MΩ Min @500V DC | |
| Withstanding Voltage: | 500V AC | |
| Durability (Mating): | 200 Times Min |
Environmental Performance:
| IP Rating: | IP66 | |
| Salt Spray: | 5% NaCl, 48h | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -40°C to +105°C |
Applications:
Electric motorcycle connectors provide reliable power and signal transmission for electric two-wheelers and related mobility systems.
Here are some main applications:
- Electric Motorcycles
- Electric Scooters
- Electric Moped Systems
- Battery Pack Connections
- Battery Charging System
- Motor Controllers
- Battery Management Systems (BMS)
- Electric Motorcycle Wiring Harnesses
- Electric Delivery Motorcycles
- Electric Off-Road Motorcycles
