USB-C 3.1 Receptacle, 24 Pin, 10 Gbps, Vertical
Introduction:
The USB-C 3.1 receptacle is a high-speed connectivity solution designed for modern electronic devices that require reliable data transmission and compact PCB integration. Featuring a single-port Type-C interface with a 24-pin configuration, this connector supports data transfer rates of up to 10 Gbps, enabling fast communication between host devices and peripherals. Its PCB mount structure with a vertical design allows efficient board layout and is suitable for applications such as laptops, tablets, consumer electronics, and industrial equipment.
The connector is engineered with a stainless steel shell with nickel plating, providing excellent durability, structural strength, and resistance to corrosion. The copper alloy contacts with gold plating ensure stable electrical performance, low contact resistance, and long mating cycle life. With rated currents of 1.25A and 5A, the connector supports both high-speed data transmission and power delivery requirements in USB-C applications.
Designed for reliability and safety, the connector features a UL94V-0 flame-retardant rating and operates within a temperature range of -40°C to +85°C, ensuring stable performance in demanding environments. This makes it an ideal choice for high-performance consumer electronics, communication devices, and embedded systems requiring dependable USB-C connectivity.
Key Features
- USB-C 3.1 receptacle supporting data speeds up to 10 Gbps
- 24-pin single-port design for stable high-speed connectivity
- Vertical PCB mount configuration for flexible board layout
- Gold-plated copper alloy contacts for reliable conductivity and durability
- Nickel-plated stainless steel shell for enhanced mechanical strength
- Rated current up to 5A, UL94V-0 flame rating, operating temperature -40°C to +85°C
Main Specifications:
General Information:
| Product No.: | YC-USB-C31-S-VT-CS4A-BK-PP-TR | |
| Connector Series: | USB 3.0 Connectors | |
| Interface Type: | Type-C | |
| Brand: | Metabee | |
| Number of Contacts: | 24 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Vertical | |
| Mounting Method: | – | |
| Mounting Feature: | – | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Stainless Steel | |
| Shell plating: | Nickel Plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 0.25A, 1.25A, 5A | |
| Rated Voltage: | – |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB-C 3.1 Receptacle, 24 Pin, 10 Gbps:
USB 3.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play nature make them one of the most ubiquitous connections in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
