USB 3.2 Connector, Type C Receptacle, 12 Pin, 10 Gbps, R/A
Introduction:
The USB 3.2 Type-C receptacle is a high-performance connector designed for reliable high-speed data transmission and compact PCB integration. Featuring a single-port Type-C interface, this connector supports data transfer speeds up to 10 Gbps, making it suitable for modern consumer electronics, industrial equipment, and embedded systems requiring fast and stable connectivity. The right-angle PCB mount design optimizes board layout in space-constrained devices while ensuring secure mechanical stability during repeated mating cycles.
Constructed with a copper alloy shell with tin plating, the connector provides strong structural integrity and enhanced corrosion resistance. The phosphor bronze contacts with gold plating ensure excellent electrical conductivity, low contact resistance, and long-term durability. Rated at 3A current and 5V voltage, the connector supports reliable power and data transmission while maintaining consistent signal performance in demanding environments.
Engineered for durability, the connector features a UL94V-0 flame-retardant rating and operates reliably within a temperature range of -40°C to +85°C. This makes it ideal for use in consumer electronics, communication devices, industrial control systems, and other applications where stable high-speed connectivity and robust mechanical performance are essential.
Key Features
- USB 3.2 Type-C receptacle with 10 Gbps high-speed data transmission
- 12-pin single-port design optimized for compact PCB layouts
- Right-angle PCB mount for efficient board space utilization
- Phosphor bronze contacts with gold plating for stable conductivity and durability
- Copper alloy shell with tin plating for corrosion resistance and mechanical strength
- 3A / 5V rating with UL94V-0 flame resistance and operating temperature from -40°C to +85°C
Main Specifications:
General Information:
| Product No.: | YC-USB-C31-S-RA-TR | |
| Connector Series: | USB 3.0 Connectors | |
| Interface Type: | Type-C | |
| Brand: | Metabee | |
| Number of Contacts: | 12 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Right Angle | |
| Mounting Method: | – | |
| Mounting Feature: | – | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Copper Alloy | |
| Shell plating: | Tin Plated | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 3A | |
| Rated Voltage: | 5V |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB 3.2 Connector, Type C Receptacle, 12 Pin, 10 Gbps:
USB 3.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play nature make them one of the most ubiquitous connections in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
