USB 3.1 Type C Receptacle, 24 Pin, 10 Gbps, Vertical
Introduction:
The USB 3.1 Type-C receptacle is a high-performance connector designed for reliable high-speed data transmission and efficient PCB integration. Featuring a single-port Type-C interface with a 24-pin configuration, this connector supports data transfer speeds of up to 10 Gbps, making it suitable for modern electronic devices that require fast communication and stable connectivity. The PCB mount design with a vertical orientation allows flexible board layout and is ideal for compact electronic products such as laptops, tablets, consumer electronics, and industrial control systems.
The connector is built with a stainless steel shell with nickel plating, providing strong mechanical strength and excellent resistance to corrosion and wear. Its copper alloy contacts with gold plating ensure superior electrical conductivity, reduced contact resistance, and long-term mating reliability. With a rated current of 1.25A to 5A, the connector supports both high-speed data transfer and power delivery requirements in modern USB-C applications.
Designed for durability and safety, the connector features a UL94V-0 flame-retardant rating and operates reliably in harsh environments with an operating temperature range from -40°C to +85°C. This makes it suitable for a wide range of applications, including consumer electronics, communication devices, embedded systems, and industrial equipment requiring dependable USB-C connectivity.
Key Features
- USB 3.1 Type-C receptacle supporting data speeds up to 10 Gbps
- 24-pin single-port design for reliable high-speed connectivity
- Vertical PCB mount structure for flexible board layout
- Gold-plated copper alloy contacts for excellent conductivity and durability
- Nickel-plated stainless steel shell for enhanced mechanical strength and corrosion resistance
- Rated current 1.25A–5A, UL94V-0 flame rating, operating temperature -40°C to +85°C
Main Specifications:
General Information:
| Product No.: | YC-USB-C31-S-VT-CS2A-BK-PP-TR | |
| Connector Series: | USB 3.0 Connectors | |
| Interface Type: | Type-C | |
| Brand: | Metabee | |
| Number of Contacts: | 24 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Vertical | |
| Mounting Method: | – | |
| Mounting Feature: | – | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Stainless Steel | |
| Shell plating: | Nickel Plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 1.25A, 5A | |
| Rated Voltage: | – |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB 3.1 Type C Receptacle, 24 Pin, 10 Gbps:
USB 3.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play nature make them one of the most ubiquitous connections in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
