USB 3.1 Type C Receptacle, 24 Pin, 10 Gbps, PCB Through Hole, Vertical
Introduction:
This female, single-port, 24-pin Type-C connector is engineered for high-speed data transfer and robust performance in a variety of electronic applications. With an impressive data rate of up to 10 Gbps, it ensures rapid and efficient communication, ideal for next-generation devices. Its vertical, PCB Through Hole mounting design provides secure and stable integration onto circuit boards, optimizing space and ensuring reliable long-term connectivity in your product designs.
Crafted for durability and superior electrical characteristics, this receptacle features a stainless steel housing with a nickel-plated finish, offering excellent protection and a professional appearance. The contacts are made from high-quality copper alloy, precisely gold-plated to ensure optimal conductivity, signal integrity, and exceptional mating cycles. Electrically, it boasts a rated voltage of 5V and multiple current ratings, including 1.25A and 5A, accommodating diverse power requirements. With a UL94V-0 flammability rating and a wide operating temperature range from -40°C to 85°C, this connector guarantees safe and consistent performance in demanding environments.
Key Features
- USB 3.1 Type-C: Modern, reversible interface.
- 10 Gbps Speed: Blazing-fast data transmission.
- Vertical Mount: Space-efficient PCB Through Hole installation.
- Premium Materials: Nickel-plated stainless steel, gold-plated copper alloy.
- Versatile Power: 5V rated voltage with 1.25A and 5A current options.
- Robust & Safe: UL94V-0 flammability and wide operating temperature.
Main Specifications:
General Information:
| Product No.: | YC-USB-C31-S-VT-CS5-BK-SS-PP-TR | |
| Connector Series: | USB 3.0 Connectors | |
| Interface Type: | Type-C | |
| Brand: | Metabee | |
| Number of Contacts: | 24 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Vertical | |
| Mounting Method: | PCB Mount | |
| Mounting Feature: | Through Hole | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Stainless Steel | |
| Shell plating: | Nickel Plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 0.25A, 1.25A, 5A | |
| Rated Voltage: | – |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB 3.1 Type C Receptacle, 24 Pin, 10 Gbps:
USB 3.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play nature make them one of the most ubiquitous connections in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
