USB 3.1 Type C Receptacle, 24 Pin, 10 Gbps, PCB Through Hole, Right Angle, Waterproof
Introduction:
The advanced USB 3.1 Type C receptacle is a high-performance 24-pin connector engineered for cutting-edge applications demanding both speed and resilience. This single-port receptacle features a convenient right-angle PCB through-hole mounting design, providing robust integration and optimal space utilization in a wide array of electronic devices. Capable of delivering lightning-fast data transfer speeds up to 10 Gbps, it ensures seamless and efficient communication. Crucially, this connector is also waterproof, making it an ideal choice for harsh environments or applications requiring enhanced protection against liquids.
Crafted for exceptional durability and reliable performance, this Type C receptacle boasts a robust stainless steel housing, meticulously nickel-plated for superior corrosion resistance and a long-lasting finish. The internal contacts are precisely formed from high-quality copper alloy and generously gold-plated, ensuring excellent conductivity, stable signal integrity, and an extended operational lifespan. With a robust rated current of 5A, it handles significant power delivery. The connector adheres to stringent safety standards with its UL94V-0 flammability rating and operates flawlessly across a wide temperature range from -40°C to 85°C, guaranteeing dependable performance in diverse and challenging conditions.
Key Features
- USB 3.1 Type C Standard: Universal 24-pin interface for future-proof connectivity.
- High-Speed 10 Gbps: Enables rapid data transfer for demanding applications.
- Waterproof Design: Provides enhanced protection against moisture and liquids.
- Right-Angle PCB Through-Hole Mount: Ensures secure, space-efficient, and robust board integration.
- Durable Construction: Stainless steel housing with nickel plating for corrosion resistance.
- Premium Contacts: Gold-plated copper alloy contacts for superior electrical performance.
Main Specifications:
General Information:
| Product No.: | YC-USB-C31-S-RA-CS18-WP-WT-30-TR | |
| Connector Series: | USB 3.0 Connectors | |
| Interface Type: | Type-C | |
| Brand: | Metabee | |
| Number of Contacts: | 24 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Right Angle | |
| Mounting Method: | PCB Mount | |
| Mounting Feature: | Through Hole | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Stainless Steel | |
| Shell plating: | Nickel plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 5A | |
| Rated Voltage: | – |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB 3.1 Type C Receptacle, 24 Pin, 10 Gbps:
USB 3.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play nature make them one of the most ubiquitous connections in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
