USB 3.1 Type-C Receptacle, 24 Pin, 10 Gbps, PCB Edge Mount, R/A
Introduction:
The USB 3.1 Type-C Receptacle is a compact and high-performance connector designed to support fast data transmission and efficient power delivery. Featuring a 24-pin single-port interface, this connector supports data transfer speeds up to 10 Gbps, making it suitable for modern consumer electronics, industrial devices, and embedded systems. The right-angle PCB edge-mount design enables efficient board space utilization while simplifying integration in slim and compact electronic products.
The connector is constructed with a stainless steel shell and nickel plating to ensure excellent mechanical durability and corrosion resistance. Copper alloy contacts with gold plating provide stable electrical performance, low contact resistance, and reliable signal integrity. With rated current options of 0.25A, 1.25A, and 5A, along with UL94V-0 flame-retardant materials and an operating temperature range from -40°C to +85°C, this USB-C connector is engineered for consistent performance in demanding environments.
Key Features
- USB 3.1 Type-C receptacle with 24-pin interface
- High-speed data transfer up to 10 Gbps
- Right-angle PCB edge-mount design for compact layouts
- Stainless steel shell with nickel plating for durability
- Gold-plated copper alloy contacts for stable conductivity
- UL94V-0 rated, operating temperature -40°C to +85°C
Main Specifications:
General Information:
| Product No.: | YC-USB-C31-S-RA-EH2.0A-BK-TR | |
| Connector Series: | USB 3.0 Connectors | |
| Interface Type: | Type-C | |
| Brand: | Metabee | |
| Number of Contacts: | 24 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Right Angle | |
| Mounting Method: | PCB Mount | |
| Mounting Feature: | Edge Mount | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Stainless Steel | |
| Shell plating: | Nickel plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 0.25A, 1.25A, 5A | |
| Rated Voltage: | – |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB 3.1 Type-C Receptacle, 24 Pin, 10 Gbps:
USB 3.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play nature make them one of the most ubiquitous connections in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
