USB 3.1 Type C, Male Plug, 12 Pin, 10 Gbps, Vertical
Introduction:
Upgrade your device connectivity with our high-performance USB 3.1 Type-C Male Plug. Engineered for speed and reliability, this 12-pin connector supports blazing-fast data transfer rates of up to 10 Gbps, making it an ideal solution for modern high-speed peripheral applications. Designed for vertical PCB mounting, its compact footprint saves valuable board space while ensuring a secure, robust connection for your electronic designs.
Built to withstand demanding environments, this connector features a durable stainless steel shell with a nickel-plated finish for enhanced corrosion resistance. The contact pins are crafted from high-quality copper alloy with gold plating, ensuring superior conductivity and signal integrity over extended lifecycles. With a wide operating temperature range of -40°C to 85°C and an UL94V-0 flammability rating, this component offers the safety and durability required for industrial and consumer electronics.
Key Features
- High-Speed Performance: Supports rapid data transfer speeds up to 10 Gbps.
- Vertical Orientation: Optimized for vertical PCB mount configurations to save space.
- Premium Materials: Features a nickel-plated stainless steel shell and gold-plated copper alloy contacts.
- High Durability: Rated for reliable operation between -40°C and 85°C.
- Safety First: Meets UL94V-0 flammability standards for fire safety.
- Versatile Specs: Single port, 12-pin design with 20V/3A power rating capability.
Main Specifications:
General Information:
| Product No.: | YC-USB-C31-PLUG-E1-SHD-BK | |
| Connector Series: | USB 3.0 Connectors | |
| Interface Type: | Type-C | |
| Brand: | Metabee | |
| Number of Contacts: | 12 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Plug | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Vertical | |
| Mounting Method: | – | |
| Mounting Feature: | – | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Stainless Steel | |
| Shell plating: | Nickel plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 1.25A, 3A | |
| Rated Voltage: | – |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB 3.1 Type C, Male Plug, 12 Pin, 10 Gbps:
USB 3.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play nature make them one of the most ubiquitous connections in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
