USB 3.1 Type C Female Connector, 24 Pin, 10 Gbps, PCB Mount, SMT, R/A, Waterproof
Introduction:
Our cutting-edge USB 3.1 Type C Female Connector is meticulously engineered for exceptional performance and durability. This 24-pin, single-port solution delivers blistering data transfer speeds of up to 10 Gbps, ensuring rapid and reliable connectivity. Designed with a right-angle, Surface Mount Technology (SMT) PCB mount, it facilitates efficient board integration, perfect for modern, compact electronic designs. Crucially, this connector boasts a waterproof design, providing enhanced protection against moisture and environmental ingress, making it ideal for devices exposed to challenging conditions.
Built to withstand harsh environments, the connector features a robust stainless steel housing with a nickel-plated finish, offering superior corrosion resistance and effective EMI shielding. Its contacts, crafted from high-quality copper alloy and generously gold-plated, guarantee optimal signal integrity, minimal resistance, and an extended operational lifespan. This connector supports a rated voltage of 20V and a current of 5A, catering to power-intensive applications. With a UL94V-0 flammability rating and a wide operating temperature range from -40°C to 85°C, this component is a reliable choice for demanding industrial, outdoor, and consumer electronics.
Key Features
- Waterproof Design: Provides robust protection against water and environmental elements.
- Ultra-High Speed: Supports USB 3.1 with data rates up to 10 Gbps.
- Versatile Type-C Female: 24-pin, single-port for modern, reversible connections.
- Space-Efficient Mounting: Right-angle, SMT PCB mount for compact designs.
- High Power Delivery: Rated for 20V and 5A for power-intensive applications.
- Premium Durability: Stainless steel housing, nickel plating, and gold-plated copper alloy contacts.
Main Specifications:
General Information:
| Product No.: | YC-USB-C31-S-RA-EH-WP-WF-BK-CS9-15-TR | |
| Connector Series: | USB 3.0 Connectors | |
| Interface Type: | Type-C | |
| Brand: | Metabee | |
| Number of Contacts: | 24 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Right Angle | |
| Mounting Method: | PCB Mount | |
| Mounting Feature: | SMT | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Stainless Steel | |
| Shell plating: | Nickel plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 5A | |
| Rated Voltage: | 20V |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB 3.1 Type C Female Connector, 24 Pin, 10 Gbps:
USB 3.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play nature make them one of the most ubiquitous connections in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
