USB 3.1 Type C Female Connector, 24 Pin, 10 Gbps, PCB Mount, SMT, R/A
Introduction:
The USB 3.1 Type-C Female Connector is a high-performance 24-pin interface designed for advanced data and power applications. Supporting transmission speeds up to 10 Gbps, this single-port connector ensures stable and efficient connectivity for consumer electronics, industrial control systems, and embedded devices. The right-angle (R/A) configuration combined with SMT PCB mount design enables optimized board space utilization and streamlined assembly processes.
Manufactured with a stainless steel shell and nickel plating, the connector provides excellent structural durability and corrosion resistance. Phosphor bronze contacts with gold plating ensure superior electrical conductivity, low contact resistance, and extended mating cycles. Rated for multiple current levels (0.25A, 1.25A, and 5A), compliant with UL94V-0 flame-retardant standards, and operating within a temperature range of -40°C to +85°C, this connector guarantees long-term reliability under demanding conditions.
Key Features
- USB 3.1 Type-C female, 24-pin high-speed interface
- Data transfer rate up to 10 Gbps
- Rated current options: 0.25A / 1.25A / 5A
- Right-angle SMT PCB mount design
- Gold-plated phosphor bronze contacts for stable performance
- UL94V-0 rated, operating temperature -40°C to +85°C
Main Specifications:
General Information:
| Product No.: | YC-USB-C31-S-RA-EH-BK-CS1-HF-TR | |
| Connector Series: | USB 3.0 Connectors | |
| Interface Type: | Type-C | |
| Brand: | Metabee | |
| Number of Contacts: | 24 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Right Angle | |
| Mounting Method: | PCB Mount | |
| Mounting Feature: | SMT | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Stainless Steel | |
| Shell plating: | Nickel plated | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 0.25A, 1.25A, 5A | |
| Rated Voltage: | – |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB 3.1 Type C Female Connector, 24 Pin, 10 Gbps:
USB 3.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play nature make them one of the most ubiquitous connections in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
