USB 3.1 Type C Connector, Plug, 12 Pin, 10 Gbps, Vertical
Introduction:
Discover the advanced USB 3.1 Type C, a high-performance, 12-pin plug meticulously designed for robust and high-speed applications. This single-port connector, with its vertical PCB mount orientation, offers exceptional versatility and space efficiency, making it an ideal choice for integrating into various electronic designs. Capable of delivering blazing-fast data transfer speeds up to 10 Gbps, it ensures seamless and efficient communication for the most demanding devices.
Engineered for superior reliability and durability, this connector features a premium stainless steel housing, nickel-plated to resist corrosion and provide a sleek, professional finish. The contacts are crafted from high-quality copper alloy, further enhanced with gold plating to guarantee optimal conductivity and signal integrity over prolonged use. Electrically, it supports flexible power delivery with rated currents of 1.25A and 3A at 20V. Its UL94V-0 flammability rating underscores a commitment to safety, while its wide operating temperature range from -40°C to 85°C ensures dependable performance in diverse and challenging environments.
Key Features
- USB 3.1 Type C Interface: Offers universal compatibility and reversible plug orientation.
- High-Speed Data Transfer: Supports data rates up to 10 Gbps for rapid communication.
- Vertical PCB Mount: Provides flexible integration and optimizes space on circuit boards.
- Durable Construction: Stainless steel housing with nickel plating ensures longevity and corrosion resistance.
- Premium Electrical Performance: Gold-plated copper alloy contacts deliver superior conductivity and stable signal.
- Wide Operating Temperature: Reliably functions from -40°C to 85°C, suitable for harsh conditions.
Main Specifications:
General Information:
| Product No.: | YC-USB-C31-PLUG-E1-BK | |
| Connector Series: | USB 3.0 Connectors | |
| Interface Type: | Type-C | |
| Brand: | Metabee | |
| Number of Contacts: | 12 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Plug | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Vertical | |
| Mounting Method: | – | |
| Mounting Feature: | – | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Stainless Steel | |
| Shell plating: | Nickel plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 1.25A, 3A | |
| Rated Voltage: | – |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB 3.1 Type C Connector, Plug, 12 Pin, 10 Gbps:
USB 3.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play nature make them one of the most ubiquitous connections in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
