USB 3.1 Gen2 Type C Plug, 24 Pin, 10 Gbps, PCB Mount, SMT, Vertical
Introduction:
The USB 3.1 Gen 2 Type-C plug is engineered for high-speed data transmission and stable power delivery in advanced electronic applications. Designed as a single-port Type-C plug with a full 24-pin configuration, it supports up to 10 Gbps data rates and delivers reliable 3A current at 20V. The vertical PCB mount and SMT design ensure efficient board space utilization and compatibility with automated assembly processes, making it ideal for compact and high-density layouts.
Constructed with a stainless steel shell and nickel-plated housing, the connector provides superior mechanical strength and corrosion resistance. The copper alloy contacts with gold plating guarantee low contact resistance, enhanced conductivity, and long mating cycle durability. Rated UL94V-0 for flame retardancy and operating within a temperature range of -40°C to +85°C, this connector ensures stable performance in demanding industrial and consumer electronics environments.
Key Features
- USB 3.1 Gen2 Type-C plug, 24-pin full-featured interface
- High-speed transmission up to 10 Gbps
- Rated 3A current and 20V voltage
- Vertical PCB mount, SMT design for automated assembly
- Stainless steel shell, nickel-plated for durability
- Gold-plated copper alloy contacts, UL94V-0, -40°C to +85°C operating range
Main Specifications:
General Information:
| Product No.: | YC-USB-C31-PLUG-H-SMT-DC-TR | |
| Connector Series: | USB 3.0 Connectors | |
| Interface Type: | Type-C | |
| Brand: | Metabee | |
| Number of Contacts: | 24 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Plug | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Vertical | |
| Mounting Method: | PCB Mount, | |
| Mounting Feature: | SMT | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Stainless Steel | |
| Shell plating: | Nickel plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 3A | |
| Rated Voltage: | – |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB 3.1 Gen2 Type C Plug, 24 Pin, 10 Gbps:
USB 3.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play nature make them one of the most ubiquitous connections in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
