USB 3.1 Gen2 Type C Female Connecto, 24 Pin, 10 Gbps, R/A
Introduction:
The USB 3.1 Gen2 Type-C female connector is engineered for high-speed data transmission and robust power delivery in compact electronic designs. Featuring a 24-pin receptacle interface and right-angle (R/A) mounting orientation, this single-port connector supports data rates up to 10 Gbps and a rated current of 5A. It is optimized for next-generation consumer electronics, industrial equipment, and embedded systems requiring reliable USB Type-C connectivity.
Constructed with a stainless steel shell and nickel plating, the connector ensures superior mechanical strength and corrosion resistance. The copper alloy contacts with gold plating deliver enhanced conductivity, low contact resistance, and long mating life. Designed to meet UL94V-0 flame-retardant standards and operate within a wide temperature range of -40°C to +85°C, this connector guarantees stable performance in demanding environments.
Key Features
- USB 3.1 Gen2 Type-C receptacle, 24-pin configuration
- High-speed data transfer up to 10 Gbps
- Rated current up to 5A for power applications
- Right-angle mounting for space-saving PCB layout
- Gold-plated copper alloy contacts for reliable conductivity
- UL94V-0 flame rating, operating temperature -40°C to +85°C
Main Specifications:
General Information:
| Product No.: | YC-USB-C31-S-RA-CS7C-BK-15-TR | |
| Connector Series: | USB 3.0 Connectors | |
| Interface Type: | Type-C | |
| Brand: | Metabee | |
| Number of Contacts: | 24 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Right Angle | |
| Mounting Method: | – | |
| Mounting Feature: | – | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Stainless Steel | |
| Shell plating: | Nickel plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 5A | |
| Rated Voltage: | – |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB 3.1 Gen2 Type C Female Connecto, 24 Pin, 10 Gbps:
USB 3.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play nature make them one of the most ubiquitous connections in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
