SAE J1772 Type 1 AC Charging Cable, EV Plug, Single Phase, 32A, 250V
Introduction
Upgrade your electric vehicle charging setup with our high-performance SAE J1772 Type 1 AC Charging Cable. Engineered for efficiency, this single-phase plug delivers a powerful 32A current at 250V, supporting a maximum charging output of 8kW. Built with a robust thermoplastic shell and silver-plated copper alloy contacts, it ensures superior conductivity and long-term durability for daily use.
Designed to withstand harsh environments, this connector features an IP65 weatherproof rating and a UL94V-0 flame-retardant grade. Whether in extreme cold (-30°C) or intense heat (50°C), it provides a safe, stable, and rapid charging experience for all Type 1 compatible electric vehicles.
Key Features:
- High Power Efficiency: Supports up to 8kW charging at 32A/250V.
- Universal Compatibility: Standard SAE J1772 Type 1 female plug.
- Superior Conductivity: Silver-plated copper alloy contacts for minimal heat.
- All-Weather Protection: IP65 rated for dust and water resistance.
- Maximum Safety: UL94V-0 flame-retardant thermoplastic housing.
- Extreme Durability: Reliable operation from -30°C to 50°C.
Main Specifications:
General Information:
| Part No.: | YC-2090-3050-32-5C | |
| Product Series: | EV Charging Cables | |
| Brand: | Metabee | |
| Charging Standards: | SAE J1772 | |
| Rated Type: | AC | |
| Power Phase: | Single Phase | |
| Connector Gender: | Plug | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Thermoplastic | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Silver Plated |
Electrical Performance:
| Rated Voltage: | 250V | |
| Rated Current: | 32A | |
| Contact resistance: | 0.5mΩ max | |
| Insulation Resistance: | >2000MΩ（DC1000V) | |
| Max charging power: | 8kW |
Environmental Performance:
| IP Rating: | IP65 | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -30°C to +50°C |
EV Charging Cables
Applications of this SAE J1772 Type 1 AC Charging Cable:
The EV charging cables are the standard used for electric vehicles in China. This standard is primarily for slower AC charging, often referred to as Level 1 or Level 2 charging. And their applications are diverse across various charging environments.
Here are some main applications:
- Private Residential Charging
- Residential Community Charging
- Workplace Charging Stations
- Public Urban Charging Stations
- Commercial and Retail Parking
- Highway Rest Area Charging
- Fleet and Commercial Vehicle Depots
- Municipal and Public Parking Lots
