SAE J1772 AC Charging Socket for EV, Single Phase, 240V, 50A
Introduction
Form the foundation of a professional-grade charging station with our SAE J1772 AC charging socket. Engineered to handle maximum power, this component is rated for 50A and 240V, delivering an immense 12kW for the fastest possible Level 2 charging. As the core of your Electric Vehicle Supply Equipment (EVSE), this socket ensures universal compatibility with all North American EVs, providing a secure and reliable connection point for high-power charging.
Built for unparalleled safety and long-term performance, this socket features a heavy-duty thermoplastic housing and silver-plated copper alloy contacts for superior electrical conductivity and corrosion resistance. It is designed to withstand harsh environments, boasting an IP65 rating for complete protection against dust and water ingress. With a top-tier UL94V-0 flame retardant classification and an operating temperature range of -30°C to 50°C, it provides maximum safety and reliability.
Key Features:
- 12kW Maximum Power: Enables elite 240V/50A performance for the fastest charging.
- SAE J1772 Standard: The essential component for building compliant EV charging stations.
- Extreme Durability: IP65-rated for robust protection against dust and moisture.
- Peak Safety: UL94V-0 flame-retardant for the highest level of fire protection.
- Superior Conductivity: Silver-plated copper contacts ensure maximum efficiency.
- All-Climate Reliability: Operates flawlessly in temperatures from -30°C to 50°C.
Main Specifications:
General Information:
| Part No.: | V3-YC-G-EV50S | |
| Product Series: | SAE Standards AC Charging Connectors | |
| Brand: | Metabee | |
| Charging Standards: | SAE J1772 | |
| Rated Type: | AC | |
| Power Phase: | Single Phase | |
| Connector Gender: | Socket | |
| Mating Cycles: | ＞10000 Times | |
| Color: | Black | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Thermoplastic | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Silver Plated |
Electrical Performance:
| Rated Voltage: | 240V | |
| Rated Current: | 50A | |
| Contact resistance: | 0.5mΩ max | |
| Insulation Resistance: | >1000MΩ（DC500V) | |
| Max charging power: | 12kW |
Environmental Performance:
| IP Rating: | IP65 | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -30°C to +50°C |
SAE J1772 Standard:
SAE J1772 Standard AC Charging Type:
SAE J1772 Charging Connector Drawing:
Applications of this SAE J1772 AC Charging Socket for EV:
The GB Standards AC Charging Connectors are the standard used for electric vehicles in China. This standard is primarily for slower AC charging, often referred to as Level 1 or Level 2 charging. And their applications are diverse across various charging environments.
Here are some main applications:
- Private Residential Charging
- Residential Community Charging
- Workplace Charging Stations
- Public Urban Charging Stations
- Commercial and Retail Parking
- Highway Rest Area Charging
- Fleet and Commercial Vehicle Depots
- Municipal and Public Parking Lots
Factory pricing and exceptional product quality. Get a free quote now!
