HSD A-Coded 4 Pin Plug to GX12 4 Pin Plug Cable
Introduction
The HSD cable is a high-performance cable assembly designed for reliable signal transmission in automotive, industrial, and data communication systems. Featuring an A-coded HSD connector on one end and a GX12 4-pin plug on the other, this assembly ensures secure connectivity between high-speed data interfaces and auxiliary devices.
Engineered with precision, the HSD connector delivers a stable 50-ohm impedance, minimizing signal loss and electromagnetic interference. The GX12 connector offers robust mechanical stability, making the cable ideal for demanding environments. With a straight plug-to-plug design, it provides ease of installation while maintaining secure and consistent electrical performance. Built for durability, this cable assembly supports a wide operating temperature range of -40°C to +105°C, ensuring dependable functionality in harsh conditions.
Key Features:
- HSD A-coded 4-pin plug to GX12 4-pin plug design
- Straight-to-straight connector orientation for easy installation
- 50Ω contact impedance for stable signal integrity
- Wide operating temperature: -40°C to +105°C
- Durable construction for automotive and industrial environments
Main Specifications:
| Part No.: | 102-11-10011 | |
| Product Series: | HSD Cables | |
| Product Type: | HSD to GX12 | |
| Brand: | Metabee | |
| Connector 1: | HSD Connector | |
| Connector 1 Coding: | A-Coded | |
| Connector 1-Number of Positions: | 4 Pin | |
| Connector 1 – Gender: | Plug | |
| Connector 1 – Orientation: | Straight | |
| Connector 1 – Mount Method: | Not Applicable | |
| Connector 2: | GX12 Connector | |
| Connector 2-Number of Positions: | 4 Pin | |
| Connector 2 – Gender: | Plug | |
| Connector 2 – Orientation: | Straight | |
| Connector 2 – Mount Method: | Not Applicable | |
| Cable Length: | Customized | |
| Impedance: | 50 Ohms | |
| Temperature Range: | -40℃ to +105℃ | |
| Other Feature: | None |
HSD plug and jack in schematic view with pin assignment:
14 codes and colors of HSD male and female:
Applications of this HSD A-Coded 4 Pin Plug to GX12 4 Pin Plug Cable:
HSD (High-Speed Data) cables are a specialized type of cable designed to meet the growing need for high-speed, reliable data transmission.
Here are some main applications:
- In-Vehicle Infotainment Systems;
- Advanced Driver-Assistance Systems (ADAS);
- Automotive Camera Systems;
- GPS and Telematics;
- Robotics and Industrial Automation;
- Medical Equipment;
- Test and Measurement Systems;
- Consumer Electronics.
We can customize this HSD cable assembly according to your special requirements. Get a free quotation now!
