GB/T DC Charger for EV, Socket, Single Phase, 750V, 125A
Introduction
This GB/T DC EV charging cocket provides a high-performance interface for DC fast-charging systems. Fully compliant with the GB/T 20234.2-2015 standard, it is engineered for single-phase DC applications, supporting a rated voltage of 750V and a current of 125A. With a maximum charging power of 93kW, this socket is a crucial component for developing rapid and efficient charging stations, ensuring a secure and reliable connection for electric vehicles.
The socket is constructed for maximum durability and safety in demanding environments. Its housing is made from high-grade thermoplastic for superior impact resistance, while the silver-plated copper alloy contacts provide excellent electrical conductivity and minimize power loss. The unit is IP65 rated, offering complete protection against dust and water, making it ideal for outdoor use. Additionally, a UL94V-0 flame retardant rating and a wide operating temperature range from -30°C to 50°C ensure uncompromising safety and performance. The required wire gauge is 3x16mm²+3x16mm²+2P(3x16mm²)+2P(3x16mm²).
Key Features:
- Rapid DC Charging: Capable of delivering up to 93kW for accelerated charging speeds.
- GB/T Standard Compliant: Ensures full compatibility with GB/T 20234.2-2015 vehicles and chargers.
- Optimal Conductivity: Silver-plated copper contacts for efficient and reliable power transfer.
- Rugged Design: Durable thermoplastic shell for long-term reliability and protection.
- Weatherproof & Safe: IP65 rated for all-weather use and UL94V-0 for fire safety.
- Wide Temperature Range: Operates effectively in temperatures from -30°C to 50°C.
Main Specifications:
General Information:
| Part No.: | NV2-YC-G-EV125S | |
| Product Series: | GB Standards DC Charging Connectors | |
| Brand: | Metabee | |
| Charging Standards: | GB/T 20234.2-2015 | |
| Rated Type: | DC | |
| Power Phase: | Single Phase | |
| Connector Gender: | Socket | |
| Mating Cycles: | ＞10000 Times | |
| Wire Gauge: | 2x35mm²+1x16mm²+2x4mm²+2P(3x16mm²)+2P(3x16mm²) | |
| Color: | Black | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Thermoplastic | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Silver Plated |
Electrical Performance:
| Rated Voltage: | 750V | |
| Rated Current: | 125A | |
| Contact resistance: | 0.5mΩ max | |
| Insulation Resistance: | >1000MΩ（DC500V) | |
| Max charging power: | 90kW |
Environmental Performance:
| IP Rating: | IP65 | |
| Flammability Rating: | UL94V-0 | |
| Operating Temperature: | -30°C to +50°C |
AC charging Type of GB standards
GB Standards DC Charging Connector
GB Standards DC Charging Connector Drawing
Applications of this GB/T DC Charger for EV:
The GB Standards DC Charging Connectors are the standard used for electric vehicles in China. This standard is primarily for slower AC charging, often referred to as Level 1 or Level 2 charging. And their applications are diverse across various charging environments.
Here are some main applications:
- Private Residential Charging
- Residential Community Charging
- Workplace Charging Stations
- Public Urban Charging Stations
- Commercial and Retail Parking
- Highway Rest Area Charging
- Fleet and Commercial Vehicle Depots
- Municipal and Public Parking Lots
Factory pricing and exceptional product quality. Get a free quote now!
