R/A Fakra HSD H-Coded 4+2 Pin Jack to R/A HSD D-Coded 4+2 Pin Jack LVDS Cable
Introduction
This high-performance HSD to HSD cable assembly is designed for advanced automotive and multimedia data transmission applications. Featuring a right-angle H-coded 4+2 pin jack on one end and a right-angle D-coded 4+2 pin jack on the other, it ensures secure connections while supporting LVDS signal integrity. Engineered with precision, it delivers stable performance in demanding environments.
Built with 50-ohm impedance and optimized for low-loss transmission, this cable guarantees reliable high-speed data transfer for infotainment, driver-assistance systems, and camera applications. With a wide operating temperature range from -40°C to +105°C, it withstands harsh automotive conditions without compromising performance.
Key Features:
- HSD to HSD LVDS cable assembly with right-angle jacks
- H-coded 4+2 pin to D-coded 4+2 pin configuration
- 50-ohm impedance for optimized signal performance
- Wide operating temperature: -40°C to +105°C
- Suitable for automotive infotainment, ADAS, and camera systems
Main Specifications:
| Part No.: | 102-11-100018 | |
| Product Series: | HSD Cables | |
| Product Type: | HSD to HSD | |
| Brand: | Metabee | |
| Connector 1: | HSD Connector | |
| Connector 1 Coding: | H-Coded | |
| Connector 1-Number of Positions: | 4+2 Pin | |
| Connector 1 – Gender: | Jack | |
| Connector 1 – Orientation: | Right Angle | |
| Connector 1 – Mount Method: | Not Applicable | |
| Connector 2: | HSD Connector | |
| Connector 2 Coding: | D-Coded | |
| Connector 2-Number of Positions: | 4+2 Pin | |
| Connector 2 – Gender: | Jack | |
| Connector 2 – Orientation: | Right Angle | |
| Connector 2 – Mount Method: | Not Applicable | |
| Cable Length: | Customized | |
| Impedance: | 50 Ohms | |
| Temperature Range: | -40℃ to +105℃ | |
| Other Feature: | None |
HSD plug and jack in schematic view with pin assignment:
14 codes and colors of HSD male and female:
Applications of this R/A Fakra HSD H-Coded Jack to R/A HSD D-Coded Jack LVDS Cable:
HSD (High-Speed Data) cables are a specialized type of cable designed to meet the growing need for high-speed, reliable data transmission.
Here are some main applications:
- In-Vehicle Infotainment Systems;
- Advanced Driver-Assistance Systems (ADAS);
- Automotive Camera Systems;
- GPS and Telematics;
- Robotics and Industrial Automation;
- Medical Equipment;
- Test and Measurement Systems;
- Consumer Electronics.
We can customize this HSD cable assembly according to your special requirements. Get a free quotation now!
