915MHz 2dBi Omni-directional Fiberglass Antenna for UAV, N Female, IP65
Introduction:
The 915MHz 2dBi omni-directional fiberglass antenna is specifically engineered for UAV communication systems requiring stable and consistent signal coverage. Operating at 915MHz, it delivers reliable RF performance with a 2dBi gain and a true omni-directional radiation pattern, ensuring seamless 360° connectivity during dynamic flight operations. The vertical polarization design enhances signal stability and minimizes interference, making it ideal for drone telemetry, control links, and low-power IoT applications.
Constructed with a high-strength fiberglass radome, this antenna is built to withstand demanding outdoor environments. Its IP65-rated enclosure ensures effective protection against dust and water, while maintaining stable electrical performance with a VSWR of ≤1.92 and 50 Ohm impedance. Supporting up to 50W input power, it operates reliably in extreme temperatures from -40°C to +85°C and endures wind speeds up to 60 m/s. The integrated DC grounding design provides essential lightning protection, enhancing operational safety in exposed installations.
Key Features
General Information:
| Product No.: | YC-FG00008 | |
| Connector Series: | Fiberglass Antennas | |
| Brand: | Metabee | |
| Connector Type: | N-Female | |
| Connector Orientation: | Straight | |
| Radome Material: | Fiberglass | |
| Dimensions: | – | |
| Color: | Customized | |
| Other Feature: | None |
Electrical Performance:
| Frequency Range: | 915MHz | |
| Gain: | 2dBi | |
| VSWR: | ≤1.92 | |
| Impedance: | 50 Ohms | |
| Radiation Pattern: | Omni-directional | |
| Polarization: | Vertical | |
| Max Power: | 50W |
Environmental Performance:
| IP Rating: | IP65 | |
| Wind Survivability: | 60 m/s | |
| Lightning Protection: | DC Grounding | |
| Operating Temperature: | -40℃ to +85℃ |
Fiberglass Antennas
Fiberglass Antenna Structure
Installation Method of Fiberglass Antennas
Applications of this 915MHz 2dBi Omni-directional Fiberglass Antenna:
Fiberglass antennas are versatile and widely used across various communication systems due to their durability, corrosion resistance, and excellent signal transmission properties.
Here are some key applications:
- IoT
- LoRaWAN
- Helium
- Marine
- Cellular Communication
- Satellite Communication
- Wireless Video Surveillance
- Mobile Phone Base Stations
