868MHz 4-6dBi UAV Jammer Fiberglass Antenna, Outdoor, IP65
Introduction:
Introducing the 868MHz 4-6dBi UAV Jammer Fiberglass Antenna, meticulously engineered to provide effective signal disruption against unauthorized drone operations. Operating within the critical 863-868MHz frequency range, this omni-directional antenna delivers a variable gain of 4-6dBi, ensuring broad and consistent signal interference coverage. Its vertical polarization and a low VSWR of ≤1.5 optimize transmission efficiency, making it an indispensable component for counter-UAV measures in security and defense applications where reliable signal suppression is paramount.
Constructed from robust Fiberglass, this antenna features an IP65 rating, guaranteeing exceptional protection against dust and water ingress in challenging outdoor environments. It is designed for extreme operational resilience, performing reliably across a wide temperature spectrum from -40°C to 85°C and capable of withstanding severe wind speeds up to 60 m/s. With a 50 Ohm impedance, a maximum input power of 50W, and integrated DC Grounding for lightning protection, this antenna ensures both operational stability and long-term durability in critical deployment scenarios.
Key Features
General Information:
| Product No.: | YC-FG00304 | |
| Connector Series: | Fiberglass Antennas | |
| Brand: | Metabee | |
| Connector Type: | Customized | |
| Connector Orientation: | Straight | |
| Radome Material: | Fiberglass | |
| Dimensions: | – | |
| Color: | Customized | |
| Other Feature: | None |
Electrical Performance:
| Frequency Range: | 868MHz | |
| Gain: | 4-6dBi | |
| VSWR: | ≤1.5 | |
| Impedance: | 50 Ohms | |
| Radiation Pattern: | Omni-directional | |
| Polarization: | Vertical | |
| Max Power: | 50W |
Environmental Performance:
| IP Rating: | IP65 | |
| Wind Survivability: | 60 m/s | |
| Lightning Protection: | DC Grounding | |
| Operating Temperature: | -40℃ to +85℃ |
Fiberglass Antennas
Fiberglass Antenna Structure
Installation Method of Fiberglass Antennas
Applications of this 868MHz 4-6dBi UAV Jammer Fiberglass Antenna:
Fiberglass antennas are versatile and widely used across various communication systems due to their durability, corrosion resistance, and excellent signal transmission properties.
Here are some key applications:
- IoT
- LoRaWAN
- Helium
- Marine
- Cellular Communication
- Satellite Communication
- Wireless Video Surveillance
- Mobile Phone Base Stations
