5G/4G LTE/3G/2G Full Band 3dBi Omni Fiberglass Antenna, N Female, IP65
Introduction:
This Full Band 3dBi omni fiberglass antenna is engineered for seamless 5G, 4G LTE, 3G, and 2G connectivity across the entire 617–6000 MHz spectrum. With a 3dBi gain and true omnidirectional radiation pattern, it delivers consistent 360° signal coverage—ideal for remote telemetry, fleet management, IoT gateways, and rural broadband installations. The vertical polarization, low VSWR (≤1.92), and 50‑ohm impedance ensure efficient signal transmission with minimal reflection loss.
Built for extreme outdoor use, the fiberglass radome is rated IP65 and operates flawlessly from -40°C to 85°C. It withstands winds up to 60 m/s and features DC grounding for integrated lightning protection. The antenna comes standard with an N Female connector, with customized connector options available upon request, offering flexible integration with professional-grade modems, routers, and base stations.
Key Features
- Full Band Coverage (617–6000 MHz) – Supports 5G, 4G, 3G, and 2G on one antenna.
- Omnidirectional Pattern – 360° coverage, no aiming required.
- 3dBi Gain – Reliable signal for outdoor and fringe-area applications.
- IP65 Weatherproof – Fiberglass body, -40°C to 85°C, 60 m/s wind survival.
- DC Grounding (Lightning Protection) – Safe for exposed rooftop or mast mounting.
- N Female + Customizable Options – Professional-grade connector with flexible customization.
Main Specifications:
General Information:
| Product No.: | YC-FG00072 | |
| Connector Series: | Fiberglass Antennas | |
| Brand: | Metabee | |
| Connector Type: | N Female or Customized | |
| Connector Orientation: | Straight | |
| Radome Material: | Fiberglass | |
| Dimensions: | 300*24*20mm | |
| Color: | White | |
| Other Feature: | None |
Electrical Performance:
| Frequency Range: | 617-6000MHz | |
| Gain: | 3dBi | |
| VSWR: | ≤1.92 | |
| Impedance: | 50 Ohms | |
| Radiation Pattern: | Omni-directional | |
| Polarization: | Vertical | |
| Max Power: | 50W |
Environmental Performance:
| IP Rating: | IP65 | |
| Wind Survivability: | 60 m/s | |
| Lightning Protection: | DC Grounding | |
| Operating Temperature: | -40℃ to +85℃ |
Fiberglass Antennas
Fiberglass Antenna Structure
Installation Method of Fiberglass Antennas
Applications of this 5G/4G LTE/3G/2G Full Band 3dBi Omni Fiberglass Antenna:
Fiberglass antennas are versatile and widely used across various communication systems due to their durability, corrosion resistance, and excellent signal transmission properties.
Here are some key applications:
- IoT
- LoRaWAN
- Helium
- Marine
- Cellular Communication
- Satellite Communication
- Wireless Video Surveillance
- Mobile Phone Base Stations
