4-Pin Blade Battery Connector for Laptop, PCB Mount, Through Hole, 3.0mm Pitch
Introduction:
This 4-pin blade battery connector is a reliable solution for integrating batteries into your laptop or other portable electronic devices. Designed for PCB mount applications, it features a through-hole design for a secure, durable connection. With a 3.0mm pitch, it ensures precise alignment and optimal electrical performance. Its low-profile design and robust construction make it ideal for space-constrained applications, providing a stable and efficient power link between the battery and the circuit board. It’s the perfect choice for professional-grade electronic projects requiring a dependable and compact power connection.
Features:
- Secure 4-pin connection for power.
- Through-hole mounting for durability.
- Compact 3.0mm pitch for tight spaces.
- PCB mount for streamlined integration.
- Ideal for laptops and portable devices.
Main Specifications:
| Part Number: | YC-A30MF-A-4P-R8S4 | |
| Product Type: | Blade Battery Connector | |
| Pitch: | 3.0 mm | |
| Insulation Material: | Nylon 9T (UL94 V-0) | |
| Contact Material: | Phosphor Bronze C5191 | |
| Contact Finish: | Gold Plating | |
| Mount Method: | PCB Mount | |
| Mount Feature: | Through Hole | |
| Current Rating: | 15A | |
| Voltage Rating: | 30V AC | |
| Insulation Resistance: | 100 MEGAOHMS MIN | |
| Contact Resistance: | 30 MILLIOHMS MAX | |
| Dielectric Voltage: | 500V | |
| Operation Temperature: | -40℃ to +105℃ | |
| Durability: | 5000 Cycles | |
| RoHS Compliant: | Yes | |
| SGS Compliant: | Yes |
Applications of this 4-Pin Blade Battery Connector
Some common applications of blade-type laptop battery connectors include:
- Standard and Ultrathin Laptops
- Gaming Laptops
- 2-in-1 Devices and Convertibles
- Custom-Built Laptops and Mini PCs
Factory pricing and exceptional product quality. OEM & ODM Services. Get a free quote now!
