12P Blade Type Battery Connector for Laptop, PCB Mount, Through Hole, 2.0mm Pitch
Introduction:
This 12P blade-type battery connector is the ideal solution for robust and reliable power connections in modern laptops and other portable electronic devices. Designed for secure PCB mounting, this through-hole connector provides excellent mechanical stability and durability. The 2.0 mm pitch ensures a compact footprint, making it perfect for space-constrained applications. With its durable construction and precise fit, this connector guarantees a stable power supply, protecting your device from power interruptions and short circuits. It is engineered to meet the demanding requirements of high-performance computing, ensuring long-lasting and efficient operation.
Features:
- 12-Pin Blade Type Connector: Secure, reliable power connection.
- PCB Through-Hole Mount: Provides superior mechanical stability.
- 0mm Pitch: Ideal for compact, space-saving designs.
- Designed for Laptops: Perfect for portable electronics.
- Durable and Stable: Ensures long-lasting, efficient performance.
Main Specifications:
| Part Number: | YC-A20M-A-12P-M8 | |
| Product Type: | Blade Battery Connector | |
| Pitch: | 2.0 mm | |
| Insulation Material: | Nylon 9T (UL94 V-0) | |
| Contact Material: | Phosphor Bronze C5191 | |
| Contact Finish: | Gold Plating | |
| Mount Method: | PCB Mount | |
| Mount Feature: | Through Hole | |
| Current Rating: | 7A per Pin | |
| Voltage Rating: | 125V AC | |
| Insulation Resistance: | 100 MEGAOHMS MIN | |
| Contact Resistance: | 30 MILLIOHMS MAX | |
| Dielectric Voltage: | 500V | |
| Operation Temperature: | -40℃ to +85℃ | |
| Durability: | 5000 Cycles | |
| RoHS Compliant: | Yes | |
| SGS Compliant: | Yes |
Applications of this 12P Blade Type Battery Connector
Some common applications of blade-type laptop battery connectors include:
- Standard and Ultrathin Laptops
- Gaming Laptops
- 2-in-1 Devices and Convertibles
- Custom-Built Laptops and Mini PCs
Factory pricing and exceptional product quality. OEM & ODM Services. Get a free quote now!
