14P Blade Type Laptop Battery Connector for PCB Mount, Through Hole, 2.0mm Pitch
Introduction:
This 14-pin Blade Battery Connector is engineered for secure and reliable power connections in laptops and other portable electronic devices. Designed for PCB mounting with through-hole technology, it ensures a strong, stable connection. The 2.0mm pitch provides precise alignment for optimal performance, while its durable construction guarantees long-lasting reliability. This connector is ideal for new product designs or for replacing existing connectors in laptop battery circuits. Its blade-type design facilitates easy insertion and removal, streamlining assembly and maintenance.
Features:
- 14-pin blade type connector.
- Secure through-hole PCB mounting.
- 0mm pitch for precise fit.
- Durable and reliable for long-term use.
- Ideal for laptop battery circuits.
Main Specifications:
| Part Number: | YC-A01MF-A-14P-M2-X | |
| Product Type: | Blade Battery Connector | |
| Pitch: | 2.5 mm | |
| Insulation Material: | Nylon 9T (UL94 V-0) | |
| Contact Material: | Phosphor Bronze C5191 | |
| Contact Finish: | Gold Plating | |
| Mount Method: | PCB Mount | |
| Mount Feature: | Through Hole | |
| Current Rating: | 7A | |
| Voltage Rating: | 30V AC | |
| Insulation Resistance: | 100 MEGAOHMS MIN | |
| Contact Resistance: | 30 MILLIOHMS MAX | |
| Dielectric Voltage: | 500V | |
| Operation Temperature: | -25℃ to +80℃ | |
| Durability: | 5000 Cycles | |
| RoHS Compliant: | Yes | |
| SGS Compliant: | Yes |
Applications of this 14P Blade Type Laptop Battery Connector
Some common applications of blade-type battery connectors include:
- Standard and Ultrathin Laptops
- Gaming Laptops
- 2-in-1 Devices and Convertibles
- Custom-Built Laptops and Mini PCs
Factory pricing and exceptional product quality. OEM & ODM Services. Get a free quote now!
