Introduction:
Combined network and peripheral connectivity defines this product, which integrates a single Gigabit Ethernet port and two USB 2.0 interfaces into one footprint. Reliable data transmission at 1G Base-T speeds ensures high-speed connectivity for industrial devices. Consistent operation is maintained throughout the 0 to 70 degrees Celsius commercial temperature range without performance loss. A robust stainless steel shield encloses the black PBT insulator to reject electromagnetic interference effectively. Visual link status relies on integrated green and yellow/green LED indicators positioned in the right-angle profile. Furthermore, gold-plated copper alloy contacts strictly maintain electrical resistance below 20 miliohms. These specialized sockets are ideal for server workstations, industrial pc motherboards, and high-density networking hubs.
Key Features
- Gigabit Performance: Supports reliable 1G Base-T Ethernet data transmission.
- Triple Interface Integration: Merges one RJ45 and dual USB ports efficiently.
- Stainless Steel Shielding: Blocks severe electromagnetic interference for clear signals.
- Precise Visual Feedback: Integrated green and yellow/green LEDs track status.
- Low Resistance Contacts: Gold plating ensures strictly under 20 miliohms.
Main Specifications:
General Information:
| Product No.: | MTJ-DUSB-88JX1-FS-RLV-M74 | |
| Series: | MTJ | |
| Category: | RJ45 and USB-A Combo Jacks | |
| Product Type: | Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 3×1 Port | |
| Number of USB Ports: | Dual USB Port | |
| USB Type: | Type A (USB 2.0) | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Speed: | 1G Base-T | |
| Integral Magnetics: | Yes | |
| PoE Rating: | Non-PoE | |
| Latch Direction: | Tab-Up | |
| Shielding: | Full Shielded | |
| LED indicator: | Left: Green, Right: Green/Yellow |
Electrical:
| Rated Voltage: | 150VAC | |
| Contact Resistance: | 20mΩ Max | |
| Insulation Resistance: | RJ: 500 Mohms Min USB: 1000 Mohms Min |
Materials and Plating:
| Insulator Material: | PBT | |
| Insulator Color: | Black | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | Stainless |
Environmental:
| Operating Temperature: | 0°C ~ +70°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
