Introduction:
Integrated network and peripheral links define this product, which combines a single RJ45 port and one USB 2.0 interface into a compact stacked profile. Reliable 10/100 Base-T data transmission speeds are supported flawlessly by the network interface for consistent connectivity. Successful operation is maintained throughout the 0°C ~ 70°C commercial temperature range without performance loss. A robust nickel-plated copper alloy shield encloses the black PBT insulator to reject electromagnetic interference effectively. Precise link activity monitoring depends on built-in orange, green, and yellow LED indicators positioned within the right-angle face. Furthermore, gold-plated phosphor bronze contacts strictly maintain electrical resistance below 30 miliohms while through hole termination secures the component to the PCB. Industrial controllers, digital media systems, and network routers frequently utilize this specialized socket.
Key Features
- 10/100 Base-T Speed: Supports reliable fast Ethernet data transmission rates.
- Hybrid Port Integration: Merges one RJ45 and one USB 2.0 port.
- Full Copper Shielding: Blocks severe electromagnetic interference for clear signals.
- Multi-color Status LEDs: Track precise link activity through integrated indicators.
- Low Resistance Contacts: Gold finish ensures conductivity below 30 miliohms.
Main Specifications:
General Information:
| Product No.: | MTJ-USB-88JX1-FS-PG-LL-M41 | |
| Series: | MTJ | |
| Category: | RJ45 and USB-A Combo Jacks | |
| Product Type: | Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 2×1 Port | |
| Number of USB Ports: | Single USB Port | |
| USB Type: | Type A (USB 2.0) | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Speed: | 10/100 Base-T | |
| Integral Magnetics: | Yes | |
| PoE Rating: | Non-PoE | |
| Latch Direction: | Tab-Up | |
| Shielding: | Full Shielded | |
| LED indicator: | Left: Orange/Green, Right: Yellow |
Electrical:
| Rated Voltage: | N/A | |
| Contact Resistance: | 30mΩ Max | |
| Insulation Resistance: | RJ: 500 Mohms Min USB: 1000 Mohms Min |
Materials and Plating:
| Insulator Material: | PBT | |
| Insulator Color: | Black | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | Copper Alloy, Nickel plated |
Environmental:
| Operating Temperature: | 0°C ~ +70°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
