3.5mm to 2.4mm Adapter, DC-26.5 GHz

Introduction

The 3.5mm to 2.4mm adapter is a high-performance RF adapter designed for seamless signal transmission between 3.5mm and 2.4mm connectors. With a precision-engineered 50-ohm contact impedance, it ensures minimal signal loss and superior electrical performance across a broad frequency range of DC to 26.5 GHz. The straight installation design provides easy connectivity, while the stainless steel housing with passivated plating enhances durability and corrosion resistance for long-term reliability in demanding environments.

This adapter features a low VSWR of 1.15:1, guaranteeing excellent signal integrity for high-frequency applications. It operates reliably in extreme conditions, with a wide temperature range of -50°C to 85°C, making it suitable for aerospace, telecommunications, and test equipment. Both connectors (3.5mm and 2.4mm) are constructed with stainless steel and passivated plating, ensuring robust mechanical strength and consistent electrical performance.

Key features:

  •  3.5mm to 2.4mm RF adapter for precise signal conversion
  • 50-ohm impedance for minimal signal loss
  • DC-26.5 GHz frequency range for high-frequency applications
  • Stainless steel housing with passivated plating for durability
  • Low VSWR (1.15:1) for superior signal integrity
  • Straight installation for easy connectivity
  • Wide operating temperature (-50°C to 85°C) for harsh environments)

Main Specifications:

Product No:  YC-3.5/2.4-JJS, YC-3.5/2.4-JKS, YC-3.5/2.4-KJS, YC-3.5/2.4-KKS
Product Series: 2.4mm Adapters
Adapter Type: 3.5mm to 2.4mm
Brand: Metabee
Orientation: Straight
Connector 1 3.5mmConnector
Connector 1 – Body Material: Stainless Steel
Connector 1 – Body Plating: Passivated
Connector 2: 2.4mm Connector
Connector 2 – Body Material: Stainless Steel
Connector 2 – Body Material: Passivated
Mount Method: Not Applicable
Impedance: 50 Ohm
VSWR:  1.15:1
Frequency Range: DC-26.5 GHz
Operating Temerature:  -50 ºC to +85 ºC
Other Feature: None


Applications of this 3.5mm to 2.4mm Adapter:

2.4 mm adapters are commonly used in RF and microwave applications, particularly where coaxial connectors are required.

Here are some applications:

  • Radar Systems;
  • Test and Measurement Equipment;
  • Satellite Communications;
  • Microwave Communications;
  • Aerospace and Defense.

We can customize this RF Adapter according to your special requirements. Get a free quotation now!

RF Adapters
Metabee is a professional electronic component manufacturer from China. We can provide all kinds of RF Adapters.
Product Series

2.4mm Adapter

Product No.

YC-3.5/2.4-JJS, YC-3.5/2.4-JKS, YC-3.5/2.4-KJS, YC-3.5/2.4-KKS

Adapter Type

3.5mm to 2.4mm

Product Name

3.5mm to 2.4mm Adapter, DC-26.5 GHz

Brand

Metabee

Orientation

Straight

Connector 1

3.5mm Connector

Connector 1 - Body Material

Stainless Steel

Connector 1 - Body Plating

Passivation

Connector 2

2.4mm Connector

Connector 2 - Body Material

Stainless Steel

Connector 2 - Body Plating

Passivation

Mount Method

Not Applicable

Impendence

50 Ohm

Frequency Range

DC-26.5 GHz

VSWR

≤ 1.15:1

Operating Temerature

-50 ºC to +85 ºC

Other Features

None
