Introduction:
This 20-pin SMT SFP socket mounts directly onto host PCBs to interface with standard optical and copper transceivers. It is designed to work inside SFC series cages, which provide mechanical port guidance and EMI containment. Copper alloy contact terminals feature 30u” heavy gold plating over a nickel underplate. This thick gold barrier delivers superior fretting corrosion protection, extending mating durability in demanding deployments. Molded from high-temperature UL 94V-0 thermoplastic, the housing withstands automated SMT reflow soldering without warping. Surface-mount solder tails maintain precise coplanarity for dependable board attachment. Operating across -40°C to +85°C, this socket suits enterprise core switches, optical transport nodes, and telecom base stations.
Key Features
-
30u” Heavy Gold Plating: Delivers superior fretting corrosion resistance and mating durability.
-
SMT Solder Leads: Ensures precise coplanarity for automated reflow assembly.
-
Standard SFF-20 Socket: Integrates seamlessly within SFC series multi-port cages.
-
UL 94V-0 Housing: Resists high reflow temperatures and prevents warping.
-
Industrial Temperature Rating: Functions reliably across -40°C to +85°C environments.
Main Specifications:
General Information:
| Product No.: | SFF-20-SG-30 | |
| Product Type: | SFP Connectors & Receptacles | |
| Pluggable Form Factor: | SFP | |
| Port Configuration: | 1 Port (20-Pin) | |
| PCB Mounting Style: | SMT | |
| Included Lightpipe : | None | |
| Included Heat Sink: | None | |
| Packaging Method: | Tray | |
| Mating Components: | SFC-1 / SFC-2 / SFC-4 / SFC-6 | |
| EMI Shielding Type: | N/A (Shielded by Cage) |
Materials and Plating:
| EMI Shielding Material: | N/A | |
| Insulator Material: | Hi-temp thermoplastic, UL 94V-0 | |
| Connector Insert Material: | N/A | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | 30u” Gold over Nickel underplate |
Environmental:
| Operating Temperature: | -40°C to +85°C | |
| Compliance: | Lead Free & RoHS Compliant |
Single Row Cage Part Number Configuration
Applications:
- Switch
- Router
- Server & Storage
- Fibre Channel and Gigabit Ethernet
- Networking & Telecommunication
