2.92mm to 2.92mm Adapter, DC-40 GHz
Introduction
The 2.92mm to 2.92mm adapter is a high-performance RF interconnect solution designed for precision signal transmission in demanding applications. Featuring a straight installation design, this adapter ensures seamless connectivity between two 2.92mm connectors, maintaining a stable 50-ohm contact impedance for minimal signal loss. Constructed with stainless steel housings and a passivated finish, it offers superior durability and corrosion resistance, making it ideal for harsh environments.
With an impressive frequency range of DC-40 GHz and a low VSWR of 1.25:1, this adapter guarantees reliable performance across a broad spectrum of high-frequency applications. Its robust construction supports operation in extreme temperatures, ranging from -50°C to 85°C, ensuring consistent functionality in both industrial and laboratory settings.
Key features:
- 2.92mm to 2.92mm straight adapter for seamless RF connections.
- 50-ohm impedance ensures optimal signal integrity.
- Stainless steel housing with passivated plating for durability.
- Low VSWR (1.25:1) minimizes signal reflection.
- Wide frequency range (DC-40 GHz) for versatile applications.
- Reliable performance in extreme temperatures (-50°C to 85°C).
- Precision-engineered for high-frequency and microwave systems.
Main Specifications:
| Product No: | YC-2.92-JJS, YC-2.92-JKS, YC-2.92-KKS, YC-2.92-KFKG, YC-2.92-KYKG | |
| Product Series: | 2.92mm Adapters | |
| Adapter Type: | 2.92mm to 2.92mm | |
| Brand: | Metabee | |
| Orientation: | Straight | |
| Connector 1 | 2.92mm Connector | |
| Connector 1 – Body Material: | Stainless Steel | |
| Connector 1 – Body Plating: | Passivated | |
| Connector 2: | 2.92mm Connector | |
| Connector 2 – Body Material: | Stainless Steel | |
| Connector 2 – Body Material: | Passivated | |
| Mount Method: | Not Applicable | |
| Impedance: | 50 Ohm | |
| VSWR: | 1.25:1 | |
| Frequency Range: | DC-40 GHz | |
| Operating Temerature: | -50 ºC to +85 ºC | |
| Other Feature: | None |
Applications of this 2.92mm to 2.92mm Adapter:
2.92mm adapters are commonly used in RF and microwave applications where high-frequency performance and precision are required.
Here are some applications:
- Microwave Modules;
- Radar Systems;
- Satellite Communication;
- Broadcasting;
- 5G Technology;
- Adapters and Transitions;
- Military and Aerospace;
- Test and Measurement Equipment.
We can customize this RF Adapter according to your special requirements. Get a free quotation now!
