Introduction:
Combined network and peripheral connectivity defines this product, which integrates one RJ45 port and two USB 2.0 ports into a single module. Standard 10/100 Base-T networking speeds are supported reliably for fast Ethernet applications. A robust nickel-plated brass shield encloses the black PBT insulator to reject electromagnetic interference effectively. Industrial environments benefit from the extreme resilience provided by the -40C ~ +85C temperature range. Built-in green and yellow LED indicators provide immediate visual link status updates. Furthermore, gold-plated contacts strictly maintain electrical resistance below 20 miliohms for flawless signal integrity. Typical applications include server motherboards, industrial pc systems, and network routers.
Key Features
- 10/100 Base-T Speed: Supports reliable fast Ethernet data transmission rates.
- Dual USB 2.0 Ports: Facilitates network and peripheral connectivity simultaneously.
- Industrial Temperature Range: Operates flawlessly between -40C and +85C.
- Full Brass Shielding: Blocks severe electromagnetic interference for signals.
- Low Resistance Contacts: Gold finish ensures conductivity below 20 miliohms.
Main Specifications:
General Information:
| Product No.: | MTJ-DUSB-88JX1-FS-PG-LH-M41C-WOT | |
| Series: | MTJ | |
| Category: | RJ45 and USB-A Combo Jacks | |
| Product Type: | Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 3×1 Port | |
| Number of USB Ports: | Dual USB Port | |
| USB Type: | Type A (USB 2.0) | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Speed: | 10/100 Base-T | |
| Integral Magnetics: | Yes | |
| PoE Rating: | Non-PoE | |
| Latch Direction: | Tab-Up | |
| Shielding: | Full Shielded | |
| LED indicator: | Left: Green, Right: Yellow |
Electrical:
| Rated Voltage: | 150VAC | |
| Contact Resistance: | 20mΩ Max | |
| Insulation Resistance: | 500mΩ Min |
Materials and Plating:
| Insulator Material: | PBT | |
| Insulator Color: | Black | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | Brass, Nickel plated |
Environmental:
| Operating Temperature: | -40°C ~ +85°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
