1.85mm to 1.85mm Adapter, DC-67 GHz
Introduction
The 1.85mm to 1.85mm Adapter is a high-performance RF adapter designed for precision connectivity in demanding applications. Featuring a straight installation orientation, this adapter ensures seamless signal transmission with a 50-ohm contact impedance, minimizing signal loss. Both connectors (male or female, as per configuration) are constructed with durable stainless steel housing and a passivated coating, enhancing corrosion resistance and longevity. With an impressive VSWR of 1.25:1, this adapter guarantees excellent signal integrity across a broad frequency range of DC to 65 GHz, making it ideal for high-frequency test systems, aerospace, and telecommunications.
Engineered for reliability in extreme conditions, the adapter operates within a temperature range of -50°C to +85°C, ensuring stable performance in harsh environments. Its robust stainless steel construction provides mechanical strength while maintaining precise electrical characteristics. Whether used in lab equipment, radar systems, or microwave devices, this adapter delivers consistent, low-loss connectivity for critical RF applications.
Key features:
- 1.85mm to 1.85mm straight adapter for seamless RF connections;
- 50-ohm impedance ensures minimal signal reflection;
- Stainless steel housing with passivated coating for durability;
- Low VSWR (1.25:1) for superior signal integrity;
- Broad frequency range (DC-67 GHz) for high-performance applications;
- Wide operating temperature (-50°C to +85°C) for extreme environments;
- Reliable stainless steel connectors with corrosion-resistant finish.
Main Specifications:
| Product No: | YC-1.85-JJS, YC-1.85-JKS, YC-1.85-KKS | |
| Product Series: | 1.85mm Adapters | |
| Adapter Type: | 1.85mm to 1.85mm | |
| Brand: | Metabee | |
| Orientation: | Straight | |
| Connector 1 | 1.85mm Connector | |
| Connector 1 – Body Material: | Stainless Steel | |
| Connector 1 – Body Plating: | Passivated | |
| Connector 2: | 1.85mm Connector | |
| Connector 2 – Body Material: | Stainless Steel | |
| Connector 2 – Body Material: | Passivated | |
| Mount Method: | Not Applicable | |
| Impedance: | 50 Ohm | |
| VSWR: | 1.25:1 | |
| Frequency Range: | DC-67 GHz | |
| Operating Temerature: | -50 ºC to +85 ºC | |
| Other Feature: | None |
Applications of this 1.85mm to 1.85mm Adapter:
1.85mm coaxial adapters are precision RF/microwave components used in high-frequency applications where minimal signal loss and impedance matching are critical.
Here are some applications:
- Optical Transmission Devices;
- Data Transmission Measurement;
- Radio Communication Equipment;
- Test and Measurement;
- Network Routers and Switches;
- Military Applications;
- Aerospace Systems;
- Satellite Communications.
We can customize this RF Adapter according to your special requirements. Get a free quotation now!
