Vertical USB 3.0 Female Connector, Type A, 9 Pin, PCB Thru-Hole
Introduction:
The vertical USB 3.0 female connector is engineered for high-speed data transmission and robust PCB integration in modern electronic devices. Designed as a single-port Type A receptacle, this connector supports USB 3.0 performance standards, delivering reliable signal integrity and enhanced bandwidth for demanding applications. Its vertical mounting orientation and through-hole PCB design ensure secure attachment, making it ideal for industrial equipment, consumer electronics, and embedded systems.
Constructed with a durable copper alloy shell and nickel plating, the connector offers excellent mechanical strength and corrosion resistance. The contacts, also made from copper alloy and gold-plated, ensure superior conductivity, low contact resistance, and long mating cycle life. With a UL94V-0 flame-retardant rating and an operating temperature range of -40°C to +85°C, this connector is built to perform reliably in harsh environments and critical applications.
Key Features
- USB 3.0 Type A female connector, 9-pin configuration
- Vertical orientation with PCB through-hole mounting
- Copper alloy housing with nickel plating for durability
- Gold-plated contacts for enhanced conductivity and reliability
- UL94V-0 flame-retardant rating for improved safety
- Wide operating temperature range: -40°C to +85°C
Main Specifications:
General Information:
| Product No.: | YC-USB-A3-S-VT-CS5 | |
| Connector Series: | USB 3.0 Connectors | |
| Interface Type: | Type-A | |
| Brand: | Metabee | |
| Number of Contacts: | 9 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Vertical | |
| Mounting Method: | PCB Mount | |
| Mounting Feature: | Thru-Hole | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Copper Alloy | |
| Shell plating: | Nickel Plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | – | |
| Rated Voltage: | – |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this Vertical USB 3.0 Female Connector:
USB 3.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play design make them among the most ubiquitous connectors in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
