USB 3.0 Type A Female Connector, 9 Pin, PCB SMT, R/A
Introduction:
The USB 3.0 Type A female connector is a high-performance interface solution designed for reliable high-speed data transfer and power delivery in modern electronic applications. This single-port receptacle features a vertical mounting orientation with surface mount technology (SMT), enabling efficient assembly on PCBs while maintaining a compact footprint. Constructed with a robust brass shell finished in tin plating, and precision copper alloy contacts with gold plating, it ensures excellent conductivity, corrosion resistance, and long-term durability. Rated at 1.5A current capacity, this connector supports USB 3.0 SuperSpeed communication, making it ideal for industrial equipment, consumer electronics, and embedded systems.
Engineered for demanding environments, this component operates seamlessly across a wide temperature range from -40°C to +85°C and complies with UL94V-0 flame retardancy standards, guaranteeing safety and stability under challenging conditions. The right-angle (R/A) orientation facilitates flexible PCB layout, optimizing space in tight enclosures. Whether used in data storage devices, docking stations, or industrial control units, this connector delivers consistent performance with its robust mechanical structure and high-reliability contact system.
Key Features
- USB 3.0 Type A receptacle with dual-port, 18-pin configuration
- Right-angle (R/A) design for space-saving PCB layouts
- Through-hole mounting (THM) for strong mechanical retention
- Stainless steel shell with tin plating for durability and shielding
- Gold-plated copper alloy contacts for high conductivity and reliability
- Wide operating temperature range (-40°C to +85°C) with UL94V-0 rating
Main Specifications:
General Information:
| Product No.: | YC-USB-A3-S-RA-SMT | |
| Connector Series: | USB 3.0 Connectors | |
| Interface Type: | Type-A | |
| Brand: | Metabee | |
| Number of Contacts: | 9 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Right Angle | |
| Mounting Method: | PCB Mount | |
| Mounting Feature: | SMT | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Brass | |
| Shell plating: | Nickel Plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Rated Current: | 1.5A | |
| Rated Voltage: | – |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB 3.0 Type A Female Connector:
USB 3.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play design make them among the most ubiquitous connectors in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
