Vertical USB 2.0 Type A Receptacle, 4 Pin, PCB Thru-Hole
Introduction:
Designed for robust and consistent performance, this Vertical USB 2.0 Type A Receptacle offers a dependable connectivity solution for a wide range of electronic devices. Featuring a single-port, 4-pin configuration, this receptacle is engineered for PCB Thru-Hole mounting, ensuring secure and stable integration onto your circuit boards. Its vertical orientation is ideal for designs requiring an upright USB port, providing versatility in product layout.
Crafted with premium materials, the connector boasts a durable brass housing with nickel plating, offering excellent corrosion resistance and longevity. The contacts are made from high-grade copper alloy and finished with gold plating, guaranteeing superior electrical conductivity and signal integrity. With an impressive current rating of 1.5A and a voltage rating of 250VAC, this connector is built to handle demanding power requirements. It also meets the UL94V-0 flammability standard, ensuring safety and compliance, and operates reliably across a broad temperature range from -40°C to 85°C.
This USB 2.0 Type A receptacle is perfect for applications where space optimization, durability, and reliable data transfer are paramount. Its thoughtful design and robust construction make it an excellent choice for industrial equipment, consumer electronics, and various other devices that require a stable and long-lasting USB interface.
Key Features
- Interface Type: USB 2.0 Type A Receptacle
- Mounting Orientation: Vertical PCB Thru-Hole
- Pin Configuration: 4-Pin, Single Port
- Material & Plating: Brass Housing (Nickel Plated), Copper Alloy Contacts (Gold Plated)
- Electrical Ratings: 1.5A Current, 250VAC Voltage
- Environmental Durability: UL94V-0 Flammability Rating, -40°C to 85°C Operating Temperature
Main Specifications:
General Information:
| Product No.: | YC-USB-A-S-RU | |
| Connector Series: | USB 2.0 Connectors | |
| Interface Type: | Type-A | |
| Brand: | Metabee | |
| Number of Contacts: | 4 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Vertical | |
| Mounting Method: | PCB Mount | |
| Mounting Feature: | Thru-Hole | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Brass | |
| Shell plating: | Nickel Plated | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold plated | |
| Insulator: | PBT |
Electrical Performance:
| Rated Current: | 1.5A | |
| Rated Voltage: | 250VAC |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this Vertical USB 2.0 Type A Receptacle:
USB 2.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play design make them among the most ubiquitous connectors in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
