Vertical USB 2.0 Type A, Receptacle, 4 Pin, PCB Thru-Hole
Introduction:
The vertical USB 2.0 Type A receptacle is a robust and industry-standard connector designed for stable data transmission and reliable power delivery in PCB applications. Featuring a single-port Type-A interface, it supports USB 2.0 high-speed communication up to 480 Mbps, ensuring efficient connectivity across a wide range of electronic devices. The vertical mounting orientation combined with through-hole PCB installation enhances mechanical strength, making it ideal for applications requiring durable and secure board-level connections.
Engineered with a brass shell and nickel plating, this connector provides excellent structural integrity and corrosion resistance. The gold-plated brass contacts ensure low contact resistance, improved conductivity, and extended mating life. Rated at 1A current, it is suitable for standard USB power requirements, while the UL94V-0 flame-retardant housing enhances safety in demanding environments. With an operating temperature range of -40°C to +85°C, this connector is well-suited for industrial, consumer electronics, and embedded system applications.
Key Features
- USB 2.0 Type-A, 4-pin receptacle, single port
- Vertical orientation, PCB thru-hole mounting for strong retention
- Brass shell with nickel plating for durability and corrosion resistance
- Gold-plated brass contacts for reliable signal transmission
- Rated 1A current, suitable for standard USB applications
- UL94V-0 rated, operating temperature -40°C to +85°C
Main Specifications:
General Information:
| Product No.: | YC-USB-A-S-VT-CS3 | |
| Connector Series: | USB 2.0 Connectors | |
| Interface Type: | Type-A | |
| Brand: | Metabee | |
| Number of Contacts: | 4 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Vertical | |
| Mounting Method: | PCB Mount | |
| Mounting Feature: | Thru-Hole | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Brass | |
| Shell plating: | Nickel Plated | |
| Contact Material: | Brass | |
| Contact Plating: | Gold plated | |
| Insulator: | PBT |
Electrical Performance:
| Rated Current: | 1A | |
| Rated Voltage: | – |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this Vertical USB 2.0 Type A, Receptacle:
USB 2.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play design make them among the most ubiquitous connectors in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
