Vertical USB 2.0 Type A Female Connector, 4 Pin, PCB Thru-Hole
Introduction:
This premium vertical USB 2.0 Type-A receptacle is engineered for space-constrained PCB designs that require high-density vertical integration. Featuring a robust Single Port 4-pin configuration, this connector utilizes Through-Hole Technology (THT) to ensure maximum mechanical stability and a secure bond to the board, making it ideal for industrial controllers, charging hubs, and peripheral devices.
The connector is built with a high-grade Nickel-Plated Brass shell for superior EMI shielding and corrosion resistance. To guarantee stable data transmission and power delivery, the Brass contacts are finished with Gold plating, supporting a rated current of 2.1A. With a wide operating temperature range of -40°C to +85°C and a UL94V-0 flame-retardant rating, this component ensures reliable performance in the most demanding environments.
Key Features
- Space-Saving Vertical Mount: Optimized for compact PCB layouts and upright interface access.
- High Power Support: Rated for 2.1A, supporting efficient power delivery and fast data sync.
- Gold-Plated Contacts: Ensures low contact resistance and long-term signal integrity.
- Rugged Metal Shell: Nickel-plated brass construction provides excellent durability and shielding.
- Industrial Durability: Operating range of -40°C to +85°C for harsh environment stability.
- Safety Guaranteed: Features UL94V-0 rated materials for high-level flame retardancy.
Main Specifications:
General Information:
| Product No.: | YC-USB-A-S-VT-CS3-BK | |
| Connector Series: | USB 2.0 Connectors | |
| Interface Type: | Type-A | |
| Brand: | Metabee | |
| Number of Contacts: | 4 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Vertical | |
| Mounting Method: | PCB Mount | |
| Mounting Feature: | Thru-Hole | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Brass | |
| Shell plating: | Nickel Plated | |
| Contact Material: | Brass | |
| Contact Plating: | Gold plated | |
| Insulator: | PBT |
Electrical Performance:
| Rated Current: | 2.1A | |
| Rated Voltage: | – |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this Vertical USB 2.0 Type A Female Connector:
USB 2.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play design make them among the most ubiquitous connectors in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
