USB 2.0 Female Connector, Type A, 4 Pin, Thru-Hole, R/A
Introduction:
Enhance your hardware connectivity with our high-performance USB 2.0 Type A Female Receptacle. Specifically designed for Right Angle (R/A) thru-hole mounting, this single-port connector provides a secure and stable interface for a wide range of PCB applications. Its robust Brass shell, finished with Nickel plating, ensures superior mechanical strength and excellent EMI shielding for consistent data integrity in both consumer and industrial electronics.
Engineered for reliability, the internal contacts are crafted from high-grade Phosphor Bronze and finished with Gold plating to maximize conductivity and prevent oxidation over time. This 4-pin connector supports a rated current of 1.5A and a voltage of 30VAC, making it versatile for power and data transmission. With a UL94V-0 flame retardant rating and a wide operating temperature range from -40°C to +85°C, it is built to withstand demanding environmental conditions.
Key Features
- Standard Type A Interface: A 4-pin single-port receptacle fully compatible with USB 2.0 protocols.
- Right Angle Mounting: Thru-hole PCB mount design for secure, space-efficient horizontal board placement.
- Premium Brass Shell: Nickel-plated brass housing provides enhanced durability and corrosion resistance.
- Gold-Plated Contacts: Phosphor Bronze contacts with gold plating ensure low resistance and long-term reliability.
- Industrial Grade Safety: Rated UL94V-0 for flame retardancy, ensuring high safety standards.
- Extreme Temperature Support: Reliable operation across a broad range from -40°C to +85°C.
Main Specifications:
General Information:
| Product No.: | YC-USB-A-S-RA-HF | |
| Connector Series: | USB 2.0 Connectors | |
| Interface Type: | Type-A | |
| Brand: | Metabee | |
| Number of Contacts: | 4 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Receptacle | |
| Contact Termination: | Solder | |
| Mounting Orientation: | Right Angle | |
| Mounting Method: | PCB Mount | |
| Mounting Feature: | Thru-Hole | |
| Shielding: | Shielded | |
| Mating Cycles: | ＞10000 Times | |
| Other Feature: | None |
Materials and Plating:
| Shell Material: | Brass | |
| Shell plating: | Nickel Plated | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold plated | |
| Insulator: | PBT |
Electrical Performance:
| Rated Current: | 1.5A | |
| Rated Voltage: | 30VAC |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -40℃ to +85℃ |
Applications of this USB 2.0 Female Connector:
USB 2.0 connectors are versatile interfaces that support both power delivery and data communication across consumer, industrial, and professional devices. Their standardization and plug-and-play design make them among the most ubiquitous connectors in modern electronics.
Here are some key applications:
- Data Transfer
- Charging Mobile Devices
- External Storage Connection
- Audio/video Peripherals
- Gaming Equipment Interfaces
- Networking Adapters
- Automotive Systems
- Medical and Healthcare Equipment
