Introduction:
Designed for ultra-high-speed data transmission, this shielded Cat6a RJ45 connector meets 10G Base-T performance standards reliably. The single port 8P8C modular jack features integrated magnetics to filter noise and ensure signal integrity in complex networks. It includes a full shield with EMI fingers to eliminate electromagnetic interference effectively during operation. The right angle through-hole design and tab-down latch orientation facilitate efficient placement on printed circuit boards. With green and yellow LEDs, users can easily monitor network status at a glance. Gold-plated phosphor bronze contacts provide superior electrical conductivity, making this connector a reliable solution for high-bandwidth data centers and telecommunication hardware.
Key Features
- 10G Base-T Performance: Supports ultra-fast data transmission up to 10 Gbps.
- Integrated Magnetics: Built-in filtering ensures superior high-speed signal integrity.
- EMI Shielding: Full shield with fingers blocks external electrical interference.
- LED Indicators: Dual green and yellow lights provide instant status monitoring.
- Right Angle Mounting: Through-hole design offers secure and stable PCB retention.
Main Specifications:
General Information:
| Product No.: | MTJ-88NX1-FS-PG-L38-M367C-WOT | |
| Series: | MTJ | |
| Category: | High Speed RJ45 Jacks | |
| Product Type: | RJ45 Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×1 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Speed: | 10G Base-T | |
| Performance Category: | CAT6a | |
| Integral Magnetics: | Yes | |
| PoE Rating: | Non-PoE | |
| Latch Direction: | Tab-Down | |
| Shielding: | Full Shield, EMI Finger | |
| LED indicator: | Left: Green/Yellow, Right: Green |
Electrical:
| Rated Current: | 1.5A | |
| Rated Voltage: | 150V AC | |
| Contact Resistance: | 20mΩ Max | |
| Insulation Resistance: | 500mΩ Min | |
| Dielectric withstanding voltage: | 2250 VDC for 1 minute |
Materials and Plating:
| Housing Material: | Thermoplastic | |
| Housing Color: | Black | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold Plating | |
| Shield Material: | Brass, Nickel Plated |
Environmental:
| Operating Temperature: | -40℃ to +85℃ | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
