Introduction:
High-speed data transmission requires a reliable stacked RJ45 connector. This 2×1 port configuration supports advanced 10G Base-T networking for servers. Integrated magnetics help filter out signal noise effectively during operation. The full stainless steel shield protects against electromagnetic interference in dense environments. Engineers use thermoplastic housing to withstand industrial soldering conditions. Phosphor bronze contacts feature gold plating for superior conductivity. The right-angle through-hole design ensures a secure mechanical fit on the board. Its latch-up and latch-down orientation facilitates easy cable management for dual ports. This modular jack is a perfect choice for modern data centers and high-density hardware.
Key Features
- 10G Base-T Performance: Supports ultra-fast 10Gbps data transmission rates.
- Integrated Magnetics: Internal filtering ensures superior high-speed signal integrity.
- 2×1 Stacked Design: Dual-port layout saves valuable PCB horizontal space.
- Full Metal Shielding: Stainless steel housing effectively blocks external interference.
- Gold Plated Contacts: Phosphor bronze terminals ensure superior signal conductivity.
Main Specifications:
General Information:
| Product No.: | MTJG-2-88JX1-FS-PG-LTP-M464Y-WOT | |
| Series: | MTJ | |
| Category: | High Speed RJ45 Jacks | |
| Product Type: | RJ45 Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 2×1 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Speed: | 10G Base-T | |
| Performance Category: | N/A | |
| Integral Magnetics: | Yes | |
| PoE Rating: | Non-PoE | |
| Latch Direction: | Tab-Up & Tab-Down | |
| Shielding: | Full Shield | |
| LED indicator: | No LED |
Electrical:
| Rated Current: | N/A | |
| Rated Voltage: | N/A | |
| Contact Resistance: | N/A | |
| Insulation Resistance: | 500mΩ Min | |
| Dielectric withstanding voltage: | 1500 VAC or 2250VDC for 1 minute |
Materials and Plating:
| Insulator Material: | Thermoplastic | |
| Insulator Color: | Black | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold Plating | |
| Shield Material: | Stainless steel, Nickel plated |
Environmental:
| Operating Temperature: | -40℃ to +85℃ | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
