SATA 15-Pin Male Power Connector for PCB, Thru Hole, Vertical
Introduction:
Upgrade your hardware builds with this reliable sata 15 pin male power connector designed for vertical pcb thru hole mounting. Engineered for secure and stable power delivery, it ensures seamless integration into demanding electronic systems.
Built to withstand harsh environments, this connector features a robust ul94v-0 flame retardant rating and a wide operating temperature range from -55c to 85c. It delivers exceptional electrical performance with a 1.5a current rating and high insulation resistance.
Key Features
- Vertical thru hole mounting for pcb
- 15 pin single port configuration
- Rated at 1.5a current capacity
- Withstands 500 vac dielectric voltage
- Ul94v-0 flame retardant material
- 55°C to 85°C operating temperature
Main Specifications:
General Information:
| Product No.: | SATA-A6-NP-VT | |
| Connector Series: | SATA Connectors | |
| Brand: | Metabee | |
| Number of Contacts: | 15 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Male | |
| Mounting Orientation: | Vertical | |
| Mounting Method: | PCB Mount | |
| Mounting Feature: | Surface Mount | |
| Polarization: | No Polarization | |
| Mating Cycles: | 500 Cycles | |
| Other Feature: | None |
Materials and Plating:
| Contact Material: | Brass | |
| Plating: | Gold flash over nickel underplate on mating area, Tin over nickel underplate on tails |
|
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Current rating: | 1.5 ampere per contact. | |
| Contact resistance: | 30 mOhms max. | |
| Insulation resistance: | 1,000 Mohms min | |
| Dielectric withstanding voltage: | 500 VAC |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -55℃ to +85℃ |
Part Number Configuration
Applications:
SATA Connector is an interface system for connecting SATA storage devices to host systems, primarily supporting data transmission and power delivery in HDDs, SSDs, servers, NAS systems, and industrial computers.
Here are some key applications:
- Computer Systems
- Storage Systems
- Servers
- Industrial Equipment
- Consumer Electronics
