SATA 15 Pin Male Power Connector for PCB, Thru Hole, R/A
Introduction:
Enhance your circuit board designs with this premium sata 7 pin male power connector featuring a right angle mounting orientation for thru hole pcb applications. It provides a space saving solution while ensuring a secure and stable power connection for your advanced electronic assemblies.
Designed for demanding conditions, this component offers superior electrical reliability with a 1.5a current rating and high resistance metrics. It is constructed with ul94v-0 flame retardant materials and operates reliably within a wide temperature range from –55°c to 85°c.
Key Features
- Right angle mounting for pcb thru hole
- 7 pin single port male configuration
- Rated at 1.5a current capacity
- Withstands 500 vac dielectric voltage
- Ul94v-0 flame retardant construction
- Operates from -55°c to 85°c
Main Specifications:
General Information:
| Product No.: | SATA-A7-NP-RT | |
| Connector Series: | SATA Connectors | |
| Brand: | Metabee | |
| Number of Contacts: | 7 Pin | |
| Number of Ports: | Single Port | |
| Connector Gender: | Male | |
| Mounting Orientation: | Right Angle | |
| Mounting Method: | PCB Mount | |
| Mounting Feature: | Thru Hole | |
| Polarization: | No Polarization | |
| Mating Cycles: | 500 Cycles | |
| Other Feature: | None |
Materials and Plating:
| Contact Material: | Brass | |
| Plating: | Gold flash over nickel underplate on mating area, Tin over nickel underplate on tails |
|
| Insulator: | Hi-Temp Thermoplastic |
Electrical Performance:
| Current rating: | 1.5 ampere per contact. | |
| Contact resistance: | 30 mOhms max. | |
| Insulation resistance: | 1,000 Mohms min | |
| Dielectric withstanding voltage: | 500 VAC |
Environmental Performance:
| Flammability Rating: | UL 94 V-0 | |
| Operating Temperature: | -55℃ to +85℃ |
Part Number Configuration
Applications:
SATA Connector is an interface system for connecting SATA storage devices to host systems, primarily supporting data transmission and power delivery in HDDs, SSDs, servers, NAS systems, and industrial computers.
