Introduction:
Simultaneous power and Fast Ethernet data delivery relies on the shielded RJ45 jacks and integrated magnetics PoE module. A full nickel-plated copper alloy shield safeguards the 10/100 Base-T connection against electromagnetic interference within commercial environments. To guarantee mechanical stability on the printed circuit board, the black PA46 insulator features a secure board lock mechanism. Visual network activity is precisely tracked by integrated green and green/yellow LEDs located in the right-angle, tab-up profile. Furthermore, gold-plated copper alloy contacts strictly maintain electrical resistance below 20mΩ to ensure long-term signal clarity from 0°C to 70°C.
Key Features
- 10/100 Base-T PoE: Combines power and Fast Ethernet data transmission reliably.
- Copper Alloy Shielding: Nickel-plated metal housing blocks electromagnetic interference effectively.
- PA46 Insulation Material: Durable black housing includes a secure board lock.
- Multi-color Status LEDs: Green and green/yellow lights track network activity clearly.
- Low Resistance Contacts: Gold-plated copper alloy strictly maintains <20mΩ electrical resistance.
Main Specifications:
General Information:
| Product No.: | MTJ-88CX1-FSP-PG-L35-M101AC-NY46 | |
| Series: | MTJ | |
| Category: | RJ45 Magnetic Jacks | |
| Product Type: | RJ45 Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×1 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Speed: | 10/100Base-T | |
| Integral Magnetics: | Yes | |
| PoE Rating: | Supports-PoE | |
| Latch Direction: | Tab-Up | |
| Shielding: | Full Shield | |
| LED indicator: | Left: Green, Right: Green/Yellow |
Electrical:
| Rated Voltage: | 150VAC | |
| Contact Resistance: | 20mΩ Max | |
| Insulation Resistance: | 500mΩ Min |
Materials and Plating:
| Insulator Material: | PA46 | |
| Insulator Color: | Black | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | Copper Alloy, Nickel plated |
Environmental:
| Operating Temperature: | 0°C ~ +70°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
