RJ45 Ethernet Jack Connector with Magnetics, 1 Port, 10/100 Base-T, Shielded with EMI, THT, R/A, No LED
Introduction:
Improving data reliability is easy with this RJ45 Ethernet connector with magnetics. Internal transformers handle essential 10/100 Base-T signal conditioning while protecting sensitive chips from electrical surges. Its rugged copper alloy shell features EMI fingers to block unwanted noise in busy networking environments. Because this model has no LED indicators, it offers a clean and professional appearance for devices that use external status displays. The right angle through hole design ensures a low-profile fit on compact circuit boards. Integrated board guides and solder retention features provide a strong mechanical bond during the assembly process.
Key Features
- Integrated Magnetics: Filters signal noise for stable 10/100 Base-T networking.
- Full EMI Shielding: Blocks interference using a robust metallic shell.
- Right Angle Profile: Optimizes space on through hole circuit boards.
- Solder Retention: Integrated guides ensure a stable mechanical attachment.
- No LED Design: Provides a clean look for front-panel interfaces.
Main Specifications:
General Information:
| Product No.: | MTJ-88TX1-FSD-PG-M4 | |
| Series: | MTJ | |
| Category: | RJ45 Magnetic Jacks | |
| Product Type: | RJ45 Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×1 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Speed: | 10/100 Base-T | |
| Integral Magnetics: | Yes | |
| PoE Rating: | Non-PoE | |
| Latch Direction: | Tab-Down | |
| Shielding: | Full Shield, EMI Finger | |
| LED indicator: | No LED |
Electrical:
| Rated Current: | 1.5A | |
| Rated Voltage: | 150V AC | |
| Contact Resistance: | 20mΩ Max | |
| Insulation Resistance: | 500mΩ Min |
Materials and Plating:
| Housing Material: | PBT | |
| Housing Color: | Black | |
| Contact Material: | Copper Alloy | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | Copper Alloy, Nickel plated |
Environmental:
| Operating Temperature: | 0°C ~ 70°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
