RJ45 8P8C Female Ethernet Network Connector, 1 Port, Unshielded, Tab-Down, Surface Mount, R/A, No LED
Introduction:
This is a single port RJ45 8P8C female ethernet network connector designed for space-saving surface mount technology on high-density circuit boards. It is constructed from hi-temp thermoplastic to survive rigorous reflow soldering processes without any structural warping. The Phosphor Bronze contacts feature a premium Gold over Nickel finish to ensure superior conductivity and a standard 1.5A current rating. By utilizing a Tab-Down right angle configuration, the component provides a low profile while maintaining a high insulation resistance of 1000MΩ Min. The unit effectively withstands dielectric voltages up to 1500 VDC to ensure electrical safety across an industrial temperature range of -40°C to +85°C. Technicians utilize this unshielded interface for compact networking equipment and telecommunication hardware requiring efficient automated assembly.
Key Features
- SMT Design: Optimized for high-efficiency automated surface mount assembly.
- 8P8C Interface: Provides standard modular connectivity for networking systems.
- Gold Plated Contacts: Delivers superior conductivity and lasting signal stability.
- Hi-Temp Thermoplastic: Survives intense heat during industrial reflow soldering.
- Wide Temperature Range: Performs reliably between -40°C and +85°C.
Main Specifications:
General Information:
| Product No.: | MTJ-885X1-SMT | |
| Series: | MTJ | |
| Category: | Single Port RJ45 Jack | |
| Product Type: | RJ45 Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×1 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Surface Mount | |
| Termination Method: | Solder | |
| Latch Direction: | Tab-Down | |
| Shielding: | Unshielded | |
| LED indicator: | No LED |
Electrical:
| Rated Current: | 1.5A | |
| Rated Voltage: | 125V AC | |
| Contact Resistance: | 25mΩ Max | |
| Insulation Resistance: | 1000mΩ Min | |
| Dielectric withstanding voltage: | 1000 VAC or 1500 VDC for 1 minute |
Materials and Plating:
| Housing Material: | Hi-temp thermoplastic | |
| Housing Color: | Black | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | N/A |
Environmental:
| Operating Temperature: | -40℃ to +85℃ | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
