Introduction:
This professional modular rj45 jack 8p8c is designed for high-performance networking on printed circuit boards. It features a right-angle orientation with a tab-up latch design to simplify cable management in tight spaces. The connector is encased in a full nickel-plated copper alloy shield to provide superior protection against electromagnetic interference. Constructed from hi-temp thermoplastic, the housing withstands the intense heat of industrial wave soldering. Inside, gold-plated phosphor bronze contacts ensure excellent electrical conductivity and resistance to oxidation. Integrated green and yellow LEDs allow for real-time visual monitoring of network activity. This single-port through-hole component is an ideal choice for durable server and router hardware.
Key Features
-
Full Shielding: Nickel-plated copper alloy housing blocks external EMI signals.
-
Integrated LEDs: Green and yellow indicators provide instant link feedback.
-
Tab-Up Orientation: Top-latch design facilitates easy cable insertion and removal.
-
Hi-Temp Thermoplastic: Durable housing withstands intense industrial wave soldering heat.
-
Gold-Plated Contacts: Phosphor bronze terminals ensure superior electrical conductivity.
Main Specifications:
General Information:
| Product No.: | MTJ-88CPX1-FS-PG-LH-HT | |
| Series: | MTJ | |
| Category: | High Speed RJ45 Jacks | |
| Product Type: | RJ45 Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×1 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Speed: | N/A | |
| Performance Category: | N/A | |
| Integral Magnetics: | No | |
| PoE Rating: | Non-PoE | |
| Latch Direction: | Tab-up | |
| Shielding: | Full Shield | |
| LED Indicator: | Left: Green, Right: Yellow |
Electrical:
| Rated Current: | 1.5A | |
| Rated Voltage: | 125V AC | |
| Contact Resistance: | 35mΩ Max | |
| Insulation Resistance: | 1000mΩ Min | |
| Dielectric withstanding voltage: | 1000 VDC for 1 minute |
Materials and Plating:
| Housing Material: | Hi-temp Thermoplastic | |
| Housing Color: | Black | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold Plating | |
| Shield Material: | Copper Alloy, Nickel plated |
Environmental:
| Operating Temperature: | -40°C to +85°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
