Modular Connector RJ45 Jack with Magnetics, 1 Port, 10/100 Base-T, Shielded with EMI, THT, R/A
Introduction:
Incorporating magnetics into the housing allows these modular connector jacks with magnetics to handle signal filtering and electrical isolation in one compact step. High-temperature thermoplastic construction ensures the part remains stable during wave soldering and intense operating conditions. By using a nickel-plated copper alloy shield, the port blocks external noise to maintain steady 10/100Base-T communication. Integrated yellow and green indicators provide a quick way to check network activity without extra board components. Because it features a wide temperature range from -45°C to 85°C, this jack serves reliably in extreme industrial environments.
Key Features
- Integrated Magnetics: Built-in filters ensure stable 10/100 Base-T signals.
- Full EMI Shielding: Metallic shell blocks outside interference for signal clarity.
- Wide Operating Temperature: Reliable performance from -45°C up to 85°C.
- Status Indicator LEDs: Yellow and green lights show network activity.
- Hi-Temp Thermoplastic: Robust housing survives demanding industrial soldering processes.
Main Specifications:
General Information:
| Product No.: | MTJ-88TX1-FSD-PG-LG-M4D1-HT | |
| Series: | MTJ | |
| Category: | RJ45 Magnetic Jacks | |
| Product Type: | RJ45 Jack | |
| Number of Positions/Contacts: | 8P8C | |
| Number of Ports: | 1×1 Port | |
| Mounting Orientation: | Right Angle | |
| Mounting Type: | Through Hole | |
| Termination Method: | Solder | |
| Speed: | 10/100 Base-T | |
| Integral Magnetics: | Yes | |
| PoE Rating: | Supports PoE | |
| Latch Direction: | Tab-Down | |
| Shielding: | Full Shield, EMI Finger | |
| LED indicator: | Left: Yellow, Right: Green |
Electrical:
| Rated Voltage: | 125VAC | |
| Contact Resistance: | 30mΩ Max | |
| Insulation Resistance: | 500mΩ Min |
Materials and Plating:
| Insulator Material: | Hi-temp Thermoplastic | |
| Housing Color: | Black | |
| Contact Material: | Phosphor Bronze | |
| Contact Plating: | Gold over Nickel Plated | |
| Shield Material: | Copper Alloy, Nickel plated |
Environmental:
| Operating Temperature: | -45°C~85°C | |
| Flammability Rating: | UL 94 V-0 |
Structure of Modular Jack
Engineering Options of RJ45 Modular Jack
Applications:
- Data Center Servers & Storage
- High-End Network Switches
- Industrial Ethernet Systems
- 5G Wireless Infrastructure
- IP Security and Surveillance
- Medical Imaging Equipment
- Smart Home and IoT Gateways
- Consumer Electronics and Gaming
